Artificial Intelligence (AI)

An AI accelerator is only as fast as the memory it can reach. Today's training silicon is bottlenecked not by compute, but by the bandwidth and energy cost of moving data between the processor, high bandwidth memory (HBM), and other accelerators. That is why advanced packaging has become a critical component of AI hardware — and why the advanced packaging market, worth roughly US$46 billion in 2024, is projected by Yole Group to exceed US$79.4 billion by 2030, with AI accelerators and data centers named as the leading drivers. For AI, packaging is no longer back-end assembly; it is where performance is engineered.

The AI Packaging Challenge

AI and high performance computing (HPC) share the same hardware problem: both process massive volumes of data using high compute density, large memory capacity, and wide interconnect bandwidth. To meet this, AI systems have moved away from general-purpose CPUs toward special-purpose accelerators — custom GPUs, application-specific integrated circuits (ASICs), and field-programmable gate arrays (FPGAs) — that deliver far higher performance per watt for AI workloads.

But the accelerator die is only half the system. Each accelerator must connect to multiple HBM stacks across a memory bus wide enough to feed thousands of parallel compute units, and increasingly to other accelerators and to optical I/O for scale-out. Three packaging capabilities decide whether that system works: memory-interconnect density, total I/O count, and energy per bit. ASE's VIPack™ platform is built to deliver all three.

Mapping AI Requirements to ASE Packaging Solutions

Rather than a single product, AI accelerators draw on a graduated set of technologies. The right choice depends on die count, memory configuration, and whether the design requires optical interconnect.

AI design requirement	ASE solution	What it delivers
High-pin-count single-die accelerator	High Performance FCBGA (HFCBGA)	High-density I/O on an organic substrate for cost-sensitive designs
ASIC + HBM co-packaging	FOCoS-CL / 2.5D IC	2μm/2μm RDL die-to-die routing; wide, short memory bus
Maximum die-to-die bandwidth	FOCoS-Bridge	Silicon-bridge D2D density up to ~200x that of conventional FCBGA
Highest interconnect density / 3D stacking	2.5D/3D IC	TSV-based vertical integration down to 0.5μm/0.5μm L/S
Energy-efficient scale-out I/O	Co-Packaged Optics (Si photonics)	Higher I/O bandwidth density and lower energy per bit

For memory-bound training silicon, FOCoS-CL places an ASIC alongside HBM stacks and connects them through a 2μm/2μm redistribution layer (RDL) — widening the effective memory bus without a silicon interposer. When a specific die pair needs the absolute highest bandwidth, Fan-Out Chip-on-Substrate-Bridge (FOCoS-Bridge) embeds a silicon bridge that delivers die-to-die (D2D) interconnect density up to roughly 200x that of conventional flip chip ball grid array (FCBGA) packaging. And as AI clusters scale beyond a single board, co-packaged optics (CPO) brings the optical engine next to the ASIC, raising I/O bandwidth density while lowering energy per bit — a decisive lever as cluster-level power becomes the binding constraint.

Customer Value: From Architecture to Volume

The advantage of sourcing these technologies from a single OSAT is co-design and turnkey execution. Because FOCoS, FOCoS-Bridge, 2.5D/3D IC, and CPO all sit within the VIPack™ platform, an AI customer can evaluate trade-offs across architectures with one partner rather than re-qualifying across vendors. ASE's Integrated Design Ecosystem™ (IDE) lets teams co-optimize signal integrity, thermal performance, and power delivery across silicon, package, and system before committing to silicon — compressing design iterations and shortening time to deployment.

ASE also applies AI to its own operations: predictive analytics in smart manufacturing improves yield and reliability for these complex packages, helping AI customers reach volume production with cost and quality under control. The result is a path from accelerator architecture to qualified, high-volume parts on one platform.

Conclusion

As models grow and clusters scale, the gap between what compute can do and what memory and interconnect can feed will keep widening — and packaging is where that gap is closed. With HFCBGA, FOCoS, FOCoS-Bridge, 2.5D/3D IC, and co-packaged optics unified under the VIPack™ platform and the IDE co-design environment, ASE gives AI architects a complete toolkit to engineer bandwidth, I/O, and energy efficiency into their next accelerator — from first architecture to volume production.

Build your next AI accelerator with ASE: Explore VIPack™ advanced packaging for AI and HPC at ase.aseglobal.com.

Frequently Asked Questions

Q: Why is advanced packaging important for AI accelerators? A: AI accelerators are limited by the bandwidth and energy cost of moving data between the processor, high bandwidth memory (HBM), and other accelerators — not by raw compute. Advanced packaging provides the high-density die-to-die interconnect, high I/O count, and energy-efficient optical I/O needed to feed thousands of parallel compute units, making it a critical determinant of AI system performance.

Q: Which ASE packaging technologies are used for AI? A: ASE offers High Performance FCBGA (HFCBGA), FOCoS and FOCoS-CL, FOCoS-Bridge, 2.5D/3D IC, and co-packaged optics (silicon photonics) — all within the VIPack™ platform. The choice depends on die count, HBM configuration, target bandwidth, and whether optical interconnect is required.

Q: How does FOCoS-Bridge help AI chips? A: FOCoS-Bridge embeds a silicon bridge die in the fan-out redistribution layer to deliver die-to-die interconnect density up to roughly 200x that of conventional FCBGA. This widens the memory and die-to-die bus between an ASIC and HBM, directly addressing the bandwidth bottleneck in AI training and inference silicon.

Q: What role does co-packaged optics (CPO) play in AI infrastructure? A: As AI clusters scale beyond a single board, electrical I/O becomes power-limited. Co-packaged optics places the optical engine next to the ASIC, increasing I/O bandwidth density and lowering energy per bit — key to scaling next-generation AI clusters and data centers within their power budgets.

Q: What is the advantage of ASE's turnkey model for AI customers? A: Because HFCBGA, FOCoS, FOCoS-Bridge, 2.5D/3D IC, and CPO all sit within the VIPack™ platform, customers evaluate architecture trade-offs with one partner. The Integrated Design Ecosystem™ (IDE) enables silicon-package-system co-design, compressing design iterations and shortening the path from architecture to qualified volume production.
