Double Side Molding
A 5G RF front-end module now packs power amplifiers, filters, switches, and dozens of passive components into a footprint that has to shrink with every handset generation. Conventional single-side molding places all of those parts on one face of the substrate, so as component counts climb, the package can only grow outward — exactly the wrong direction when the phone, watch, or earbud has no board area to spare. ASE's Double Side Molding (DSM) breaks that trade-off by populating and molding both faces of the package, turning a flat layout into a two-story one.
What Double Side Molding (DSM) Does Differently
DSM uses a two-sided assembly structure: active dies and passive components are mounted and molded on both the top and bottom of the substrate, typically using a fine-pitch surface-mount technology (SMT) process to fit the most components into the smallest area. To keep the resulting package thin despite stacking parts on two faces, ASE applies a backside grinding process that reduces the height of the bottom-side molding compound, die, and solder ball (or copper pillar). The result is a system-in-package that integrates far more functionality per unit of board area than single-side molding, without the z-height penalty that two-sided assembly would otherwise incur.
This makes DSM especially well suited to the RF front-end module (FEM), where the number of integrated components keeps surging as 5G adds bands and carrier-aggregation paths. Rather than spreading that growing parts count across an ever-larger single-side package, DSM absorbs it vertically.
Quantified Advantages of DSM
The benefits of two-sided integration are concrete, not directional:
- 20–40% smaller X-Y footprint than an equivalent single-side molding package — the headline gain for any board-constrained design.
- Thinner overall profile than single-side molding, enabled by the backside grinding step that trims the bottom-side stack.
- Lower packaging cost, because integrating more components within a single mold tool raises density and consolidates process steps.
- More functionality through double-side integration, letting one module replace what previously required multiple discrete packages.
- Better external thermal dissipation via exposed die, giving heat a direct path out of the package for components that run hot.
Each of these maps to a design decision. The 20–40% area reduction frees board space for battery or antenna; the thinner profile fits z-height budgets measured in fractions of a millimeter; the exposed-die thermal path preserves RF performance in power amplifiers that would otherwise derate as they heat.
Package Options: BGA and LGA
ASE offers DSM in both Ball Grid Array (BGA) and Land Grid Array (LGA) terminations, the latter available in Electroless Nickel Immersion Gold (ENIG) or pre-solder finishes — so designers can match the second-level interconnect to their board assembly process.
| DSM capability | Specification |
|---|---|
| I/O pitch, BGA (solder ball) | ≥ 0.35mm |
| I/O pitch, LGA (ENIG or pre-solder) | ≥ 0.28mm |
| Package-level reliability | Pass |
| Board-level reliability | Pass |
The finer 0.28mm pitch available on LGA lets a design route more I/O out of the same footprint, while the BGA option at 0.35mm pitch suits modules that need the standoff and reworkability of solder balls. Both terminations have passed package-level and board-level reliability qualification — the gating requirement before any RF module enters a mobile product.
EMI Shielding with Compartment Structures
RF front-end modules cannot tolerate crosstalk between sensitive blocks, so DSM optionally integrates compartment shielding directly into the package. ASE implements this with structures such as a wire cage, wire fence, or vertical wire that isolate sensitive components or chipsets from electromagnetic interference (EMI). Building the shield into the molded package — rather than relying on a separate board-level can — keeps the isolation tight and the footprint small, which matters most in the densely packed RF sections where DSM is typically deployed.
Where DSM Fits: 5G RF Front-End and Wearables
DSM is ideal for any system-in-package that needs high functional integration in a small footprint. The clearest fit is the RF front-end module — including PAMiD and PAMiF modules, Wi-Fi modules, and mmWave FEM modules — where 5G drives both component count and isolation requirements upward at the same time. Beyond the RF front end, DSM's combination of small footprint and thin profile suits wearable devices such as smartwatches and true wireless stereo (TWS) earbuds, where every cubic millimeter competes with the battery. In each case, DSM lets the system designer integrate more into a module that takes less board area than the single-side alternative.
DSM Within ASE's System-in-Package Portfolio
Double Side Molding is one of several system-in-package (SiP) architectures ASE offers, alongside Fan-Out System-in-Package (FOSiP), 3D System-in-Package, Antenna in Package, and powerSiP™. Choosing among them is an application question: DSM excels where two-sided SMT integration and EMI compartmentalization deliver the smallest RF module, while fan-out approaches lead where ultra-fine redistribution layer (RDL) routing is the priority. ASE's Integrated Design Ecosystem™ (IDE) supports co-design across these options, helping customers select and verify the right SiP architecture before committing to build.
Conclusion
As 5G and wearable designs cram more RF and mixed-signal content into shrinking footprints, the packaging question becomes how to grow integration without growing area. Double Side Molding answers it by building on both faces of the substrate, delivering a 20–40% smaller footprint, a thinner profile, integrated EMI shielding, and exposed-die thermal performance — all qualified at package and board level. As the world's largest outsourced semiconductor assembly and test (OSAT) provider, ASE delivers DSM as part of a broad SiP portfolio backed by co-design tools and volume manufacturing, so a dense RF module can move from concept to production on a single platform.
Explore Double Side Molding and ASE's SiP portfolio: Learn how ASE's system-in-package technologies can integrate your next RF or wearable design into a smaller footprint at ase.aseglobal.com.
Frequently Asked Questions
Q: What is Double Side Molding (DSM) in semiconductor packaging? A: Double Side Molding is a system-in-package (SiP) technology in which active dies and passive components are mounted and molded on both the top and bottom faces of the substrate, rather than only one side. A fine-pitch SMT process maximizes component density, and a backside grinding step keeps the package thin. DSM is especially suited to RF front-end modules and other highly integrated, space-constrained designs.
Q: How much smaller is a DSM package than a single-side molding package? A: ASE's DSM packages are 20–40% smaller in X-Y footprint than an equivalent single-side molding package, and they are also thinner overall thanks to the backside grinding process. Because more components are integrated within a single mold tool, DSM can also lower packaging cost while increasing functionality.
Q: What I/O pitch and reliability does ASE's DSM support? A: ASE's DSM supports an I/O pitch of ≥ 0.35mm for BGA (solder ball) terminations and ≥ 0.28mm for LGA terminations (ENIG or pre-solder finishes). Both options have passed package-level and board-level reliability qualification.
Q: How does DSM handle EMI in RF modules? A: DSM can integrate compartment shielding directly into the molded package using structures such as a wire cage, wire fence, or vertical wire. These isolate sensitive components or chipsets from electromagnetic interference (EMI) without requiring a separate board-level shield, keeping the module footprint small.
Q: What applications use Double Side Molding? A: DSM is widely used for 5G RF front-end modules (FEM), including PAMiD, PAMiF, Wi-Fi, and mmWave FEM modules, where component counts and EMI isolation needs are high. Its small, thin form factor also suits wearable devices such as smartwatches and true wireless stereo (TWS) earbuds.
