Package Design
The most expensive packaging mistake is the one you find on silicon. A thermal hot spot, a warped BGA, or a marginal signal path discovered after first build can cost months and a mask set. ASE's answer is to move those answers earlier — to let a designer get the thermal resistance of a package in about three hours instead of waiting on a build, and to do it from a browser. That capability is not new: ASE has run web-based packaging design services, branded e-Service, since 1999, and has spent the decades since turning packaging know-how into simulation tools that circuit designers can drive themselves before committing to a layout.
Front-Loading the Answers That Used to Wait for Silicon
Package design is where electrical, thermal, and mechanical constraints collide, and resolving them late is what drives respins. ASE provides technical analysis and consulting services — built on technical know-how derived from decades of supporting semiconductor packaging development and manufacturing — that give circuit designers maximum flexibility while those constraints are still cheap to change. The delivery mechanism is e-Service, a web-based platform initiated by ASE's R&D division to speed up the IC packaging development process.
Through interactive windows, a user assigns simulation models to derive optimal results against electrical and thermal specifications, generates bonding diagrams from a specific lead frame or substrate, and opens cases directly to ASE's characterization labs through the OLES channel. In other words, the same portal that runs the simulation also routes the harder questions to the people and instruments that can measure them — keeping early design exploration and deep lab characterization in one workflow.
Three Simulators, Three Failure Modes
ASE's e-Service exposes three remote simulators, each aimed at a different way a package can fall short.
| Simulator | In service since | What it solves | Method | Coverage |
|---|---|---|---|---|
| e-Thermal | 1999 | Thermal resistance | FEM via ANSYS | QFP (PQFP, LQFP, TQFP); BGA (PBGA, HSBGA) |
| e-Stress | 2008 | Stress and warpage | FEM via ANSYS | BGA package type |
| e-Electrical | (e-Service cloud) | Package electrical data | 3D electromagnetic solver | On-demand estimates + accurate models on request |
The e-Thermal Simulator lets a user obtain the thermal resistance of a package within three hours by entering design parameters from a remote site. It uses finite element methods (FEM) on the ANSYS commercial solver: once the package's basic dimensions and conditions arrive from the remote site, e-Thermal calls the ANSYS server, runs the analysis, and e-mails the results back. Up-to-date models cover QFP — including PQFP, LQFP, and TQFP — and BGA, including PBGA and HSBGA.
The e-Stress Simulator, in service since 2008, answers the mechanical question. After entering design parameters on the e-Stress web page, a user obtains the stress and warpage distribution of a BGA package, again computed by ANSYS under FEM and returned by e-mail. Warpage is what makes a BGA fail to mount or crack in reflow, so resolving it in simulation protects second-level reliability before any board is built.
The e-Electrical Simulator closes the loop on signal and power integrity. ASE's Electrical Laboratory has compiled its simulation and design cases into a cloud database within e-Service, so a customer can inquire estimated package electrical data wherever and whenever they need it. When an estimate is not enough, the same portal requests an accurate electrical model generated by a 3D electromagnetic solver.
From Remote Simulation to a Full Design Ecosystem
These simulators are the self-service front end of a deeper capability. ASE's characterization labs — the same labs e-Service routes cases to — supply the measured data that validates a simulation and grounds a consulting recommendation. And for chiplet-era designs where package and system are co-designed from the start, ASE's Integrated Design Ecosystem™ (IDE 2.0) extends design enablement beyond single-package simulation: the knowledge base credits IDE 2.0 with reducing design iteration time by up to 90% for advanced heterogeneous integration (HI) work. Together they let a customer move from a browser-based thermal check on a QFP all the way to AI-assisted co-design of a multi-die VIPack™ package without leaving ASE's design environment.
What Comes Next
As packages absorb more of the system — more dies, tighter thermal budgets, faster interfaces — the cost of discovering a problem on silicon only rises, and the value of resolving it in simulation rises with it. ASE's package design services, anchored by e-Service simulators that have answered thermal, stress, and electrical questions since 1999, and extended by characterization labs and the Integrated Design Ecosystem™, give product teams a way to converge on a manufacturable package before the first build — the cheapest place a design problem can possibly be solved.
Want thermal, stress, or electrical answers before you commit to a layout? Explore ASE's package design and laboratory services at ase.aseglobal.com.
Frequently Asked Questions
Q: What is ASE's e-Service? A: e-Service is ASE's web-based packaging design platform, initiated by its R&D division in 1999 to speed up IC packaging development. Through interactive windows, designers assign simulation models for electrical and thermal results, generate bonding diagrams from a specific lead frame or substrate, and open cases to ASE's characterization labs through the OLES channel — combining self-service simulation and deep lab characterization in one workflow.
Q: How long does ASE's e-Thermal Simulator take? A: The e-Thermal Simulator, in service since 1999, returns the thermal resistance of a package within three hours. After a user enters design parameters from a remote site, it runs a finite element method (FEM) analysis on the ANSYS solver and e-mails the results back. It covers QFP (PQFP, LQFP, TQFP) and BGA (PBGA, HSBGA) packages.
Q: What does the e-Stress Simulator analyze? A: The e-Stress Simulator, in service since 2008, computes the stress and warpage distribution of a BGA package using finite element methods on the ANSYS solver. Warpage is a primary cause of BGA mounting failures and reflow cracking, so resolving it in simulation protects second-level reliability before a board is built.
Q: How does ASE help with package electrical performance? A: ASE's Electrical Laboratory has compiled its simulation and design experience into a cloud database within e-Service, letting customers inquire estimated package electrical data on demand. For higher accuracy, the same portal requests an electrical model generated by a 3D electromagnetic solver.
Q: How does package design connect to ASE's advanced packaging? A: ASE's e-Service simulators and characterization labs handle single-package thermal, stress, and electrical work, while the Integrated Design Ecosystem™ (IDE 2.0) extends design enablement to chiplet-era co-design — credited in ASE's knowledge base with reducing design iteration time by up to 90% for heterogeneous integration. A customer can move from a browser thermal check to AI-assisted multi-die VIPack™ co-design within one environment.
