2.5D and 3D IC Packaging
When an AI training accelerator needs to sit microns away from its high bandwidth memory (HBM), the package — not the transistor — sets the bandwidth ceiling. 2.5D and 3D IC packaging answer that need by placing chiplets on a silicon interposer or stacking them vertically, achieving die-to-die interconnect density that organic substrates cannot approach. ASE pioneered this category, delivering the world's first mass production of a 2.5D IC package equipped with HBM, and continues to extend it for the AI, HPC, and data-center era.
What 2.5D and 3D IC Packaging Are
Both are methodologies for including multiple ICs in the same package. In a 2.5D structure, two or more active chips are placed side-by-side on a silicon interposer to achieve extremely high die-to-die (D2D) interconnect density. In a 3D structure, active chips are integrated by die stacking for the shortest possible interconnect and the smallest package footprint. In recent years both have become preferred chiplet integration platforms precisely because they combine extreme packaging density with high energy efficiency.
The Specifications That Set 2.5D/3D Apart
The differentiation is in the routing and I/O density. ASE's 2.5D/3D IC packaging achieves ultra-high routing density at line width/line spacing (L/S) of 0.4μm/0.4μm and ultra-high I/O density exceeding 400 microbumps/mm², with I/O pitch that scales further. A silicon interposer with through silicon via (TSV) bridges the fine-pitch capability gap between the assembly substrate and the integrated circuit — keeping the pad-pitch scaling path open without being limited by substrate technology.
For the designer, 0.4μm/0.4μm L/S and 400+ microbumps/mm² are what make it possible to integrate GPU, CPU, and memory together with decoupling capacitors in one package, feeding thousands of compute lanes with the bandwidth they need. The interposer can also embed decoupling capacitors or active devices, and the platform meets the reliability requirements for automotive applications — extending 2.5D/3D beyond the data center.
From 2.5D Interposer to High-Density Fan-Out
ASE established its leadership in 2.5D by bringing pioneering ASIC-plus-HBM products to market. To carry that momentum forward, ASE is introducing high-density fan-out technology for die stacking and multi-die solutions — extending high-bandwidth, high-performance integration from high-density data centers down to consumer and mobile designs. This gives customers a continuum: full 2.5D silicon-interposer density where the design demands it, and cost-efficient fan-out alternatives such as Fan-Out Chip-on-Substrate (FOCoS) and FOCoS-Bridge where it does not.
Applications: GPU, FPGA, Networking, and AI Training
2.5D/3D IC packaging is used primarily to integrate HBM in high-end GPUs, high-end FPGAs, network switches and routers for data center and 5G infrastructure, and AI accelerators for AI training. In the chiplet era, its role is expanding into CPUs, mobile application processors (APs), silicon photonics, and display driver ICs — anywhere the bandwidth and density of a side-by-side or stacked architecture create a system advantage.
Within the VIPack™ Platform
2.5D/3D IC is the TSV-based pillar of ASE's VIPack™ platform, complementing the fan-out pillars (FOCoS, FOCoS-Bridge, FOPoP, FOSiP) and the integrated-optics roadmap. ASE's Integrated Design Ecosystem™ (IDE) lets customers co-optimize the interposer, package, and system together — managing signal integrity, thermal behavior, and power delivery across these high-density architectures before silicon commitment.
Conclusion
2.5D and 3D IC packaging remain the density ceiling of advanced packaging: 0.4μm/0.4μm L/S, 400+ microbumps/mm², and the proven path that first brought HBM-equipped accelerators to volume. As the world's largest outsourced semiconductor assembly and test (OSAT) provider — and the pioneer of mass-produced 2.5D with HBM — ASE pairs this density with fan-out alternatives and co-design tools, so customers can match interconnect density to cost across the full VIPack™ platform.
Explore 2.5D/3D IC packaging and the VIPack™ platform: See how ASE's silicon-interposer and die-stacking technologies can feed your AI and HPC silicon at ase.aseglobal.com.
Frequently Asked Questions
Q: What is the difference between 2.5D and 3D IC packaging? A: In 2.5D, two or more active chips sit side-by-side on a silicon interposer for extremely high die-to-die (D2D) interconnect density. In 3D, active chips are stacked vertically for the shortest interconnect and smallest footprint. Both enable high-density, energy-efficient chiplet integration.
Q: What routing and I/O density does ASE's 2.5D/3D IC packaging achieve? A: It reaches ultra-high routing density at line width/line spacing (L/S) of 0.4μm/0.4μm and ultra-high I/O density exceeding 400 microbumps/mm², with scalable I/O pitch — enabled by a silicon interposer with through silicon via (TSV).
Q: Why use a silicon interposer with TSV? A: The TSV interposer bridges the fine-pitch gap between the assembly substrate and the IC, keeping the pad-pitch scaling path open without being limited by substrate technology. It can also embed decoupling capacitors or active devices for power and functional integration.
Q: What applications use 2.5D/3D IC packaging? A: Primarily HBM integration in high-end GPUs, FPGAs, network switches/routers for data center and 5G, and AI training accelerators — expanding into CPUs, mobile APs, silicon photonics, and display driver ICs in the chiplet era.
Q: How does 2.5D/3D IC relate to ASE's fan-out technologies? A: 2.5D/3D IC is the TSV-based pillar of VIPack™, offering maximum density. Where a design doesn't require 0.4μm/0.4μm routing everywhere, fan-out options like FOCoS (2μm/2μm) and FOCoS-Bridge provide lower-cost alternatives within the same platform.
