Embedded Die Substrate
Most packages mount the die on top of the substrate. Embedding it inside changes what the package can do. By building the semiconductor die into the substrate itself rather than placing it on the surface, ASE's embedded die substrate technologies shorten interconnects to the die, free the top surface for other components, and shift the design from a 2D layout to a 3D one. The payoff is split across two distinct technologies for two distinct problems: a-EASI handles power electronics dissipating more than 1,000W in a package footprint under 50mm², while SESUB packs up to 1,000 I/O into a substrate as thin as 280μm for highly integrated modules. Same embedding principle, opposite ends of the design space.
What Embedding the Die Actually Changes
Conventionally, an active die is mounted on top of a substrate that provides structural support and electrical interconnect. In an embedded die substrate, the die is built into standard PCB material — a stack of organic laminated layers — and/or a lead frame during the formation of the substrate itself. It is then connected to the other components on or in the substrate through copper-plated vias and conductive traces.
That structural change produces three benefits that a surface-mounted die cannot match. Miniaturization and design flexibility come first: embedding the chip frees space for other components or shrinks the overall solution, and the design moves from 2D into 3D. Electrical and thermal performance improve next, because the shorter interconnections cut parasitics — reducing distortion and power loss — while lower electrical and thermal resistivity in the package improves power handling. Reliability follows, with the stable copper (Cu) interconnections delivering high mechanical stability. ASE offers this as a full turnkey solution, drawing on its advanced packaging and test expertise together with in-house substrate design and manufacturing.
a-EASI: Built for Power
Advanced Embedded Active System Integration (a-EASI) is ASE's embedded technology for power electronics. It applies a metal lead frame for die placement, which is the source of its two defining advantages: high thermal dissipation and an electromagnetic interference (EMI) benefit, with the short connection path running through a Cu via structure. The result is a package that reduces power loss and dissipates heat aggressively while staying mechanically robust — exactly the profile that MOSFET, IGBT, regulator, DC-DC, and power-module applications demand.
| a-EASI attribute | Value |
|---|---|
| Pinout | BGA / LGA / QFN |
| I/O count | Up to 100 |
| Package size | Under 50mm² |
| Power handling | 1,000+ W |
| Thermal | Excellent |
| Target devices | MOSFET, IGBT, regulator, power modules, DC-DC |
a-EASI comes in three structures tuned to different needs. The P1 structure routes a via directly onto the chip pad for excellent electrical and thermal performance, and is already proven in high-volume manufacturing (HVM). The P2 structure adds an exposed pad for thermal enhancement in a thinner package, supports BGA, LGA, and QFN footprints, has passed AEC-Q100 Grade 1 for a single die by a customer, and embeds up to 8 chips (under customer qualification). The P3 structure also uses a via directly on the chip pad, improving design flexibility for vertical-current devices while pushing higher integration into a smaller form factor.
SESUB: Built for Integration Density
Semiconductor Embedded in Substrate (SESUB) embeds a thinned IC inside a laminated substrate, which can then be populated with other electronic components to form a highly integrated, multi-function module or package. Where a-EASI optimizes for power, SESUB optimizes for micro-modularization — consolidating functional circuitry such as high-performance power management units (PMUs) for smartphones and Bluetooth modules into a single thin body. It is a proven technology already adopted by many customers and IC vendors.
| SESUB attribute | Value |
|---|---|
| Structure | 1-2-1, 4-layer |
| Substrate thickness | Max 280μm |
| Die thickness | Min 50μm |
| Pinout | BGA / LGA |
| I/O count | Up to 1,000 |
| Package size | 200+ mm² |
| Power | Under 20+ W |
| Reliability | JEDEC MSL3 certified |
The SESUB structure is a 1-2-1 four-layer build that delivers size reduction, thermal dissipation, mechanical robustness, and performance improvement at once. With a substrate thickness capped at 280μm and die thinned to a minimum of 50μm, it serves both as a module and as a thin package in its own right. Multiple dies can be embedded; the structure enhances heat dissipation, mitigates unwanted noise radiation, and maintains robust copper connection while supporting surface-mount technology (SMT) on the substrate surface. Its application reach is broad — MCU, front-end module (FEM), PMIC, optical, connectivity, audio, power, sensor, processor, image module, automotive ADAS, high-frequency, and memory.
Choosing Between Them
The two technologies are complementary, not competing, and the choice follows the dominant constraint. When the design is power-bound — discrete MOSFETs, IGBTs, or power modules that have to shed more than 1,000W from under 50mm² — a-EASI's lead-frame structure and excellent thermal path is the fit. When the design is integration-bound — a smartphone PMU, a Bluetooth or sensor module that has to consolidate up to 1,000 I/O of functionality into a 280μm-thin body — SESUB's laminated multi-die structure is the answer. Both are extensions of ASE's broader system-in-package (SiP) and heterogeneous integration (HI) capability, where embedded chip packaging sits alongside copper wiring, flip chip, wafer-level, and 2.5D/3D IC as a building block of higher-level integration.
Where Embedded Die Goes Next
As products demand more chips and functions, higher performance, lower power, and better heat dissipation in ever-smaller form factors, demand for embedded die substrates such as a-EASI and SESUB is expected to keep rising globally. The embedding principle answers all four pressures at once: it shrinks the footprint, shortens the interconnect, spreads the heat, and stabilizes the structure. With a-EASI proven in HVM for power and SESUB certified to JEDEC MSL3 for integration, ASE gives power-electronics and module designers a manufacturable route to put the die where the performance is — inside the substrate.
Designing a power module or a highly integrated module that needs the die inside the substrate? Explore ASE's embedded die substrate and system-in-package capabilities at ase.aseglobal.com.
Frequently Asked Questions
Q: What is an embedded die substrate? A: An embedded die substrate builds the semiconductor die into the substrate itself — within standard PCB material (organic laminated layers) and/or a lead frame during substrate formation — rather than mounting it on top. The die connects to other components through copper-plated vias and conductive traces. Embedding shortens interconnects, frees the top surface for other components, and shifts the design from 2D to 3D, improving miniaturization, electrical and thermal performance, and mechanical reliability.
Q: What is the difference between a-EASI and SESUB? A: Both embed the die, but they target opposite problems. Advanced Embedded Active System Integration (a-EASI) is built for power electronics — it uses a metal lead frame for high thermal dissipation and EMI benefit, handling 1,000+ W in a package under 50mm² with up to 100 I/O, for MOSFET, IGBT, regulator, and power-module applications. Semiconductor Embedded in Substrate (SESUB) is built for integration density — it embeds a thinned IC in a laminated substrate as thin as 280μm with up to 1,000 I/O, for highly integrated modules such as smartphone PMUs and Bluetooth modules.
Q: What are the a-EASI P1, P2, and P3 structures? A: P1 routes a via directly onto the chip pad for excellent electrical and thermal performance and is proven in high-volume manufacturing (HVM). P2 adds an exposed pad for thermal enhancement in a thinner package, supports BGA/LGA/QFN footprints, has passed AEC-Q100 Grade 1 for a single die by a customer, and embeds up to 8 chips under customer qualification. P3 also uses a via directly on the chip pad, improving design flexibility for vertical-current devices in a smaller, higher-integration form factor.
Q: How thin is a SESUB package? A: SESUB uses a 1-2-1 four-layer structure with a substrate thickness of at most 280μm and a die thinned to a minimum of 50μm. It is JEDEC MSL3 certified, supports up to 1,000 I/O in a BGA/LGA pinout, and can embed multiple dies while enhancing heat dissipation and mitigating noise radiation.
Q: What applications use embedded die substrates? A: a-EASI targets power devices — MOSFET, IGBT, regulator, DC-DC, and power modules. SESUB targets highly integrated modules across MCU, front-end module (FEM), PMIC, optical, connectivity, audio, power, sensor, processor, image module, automotive ADAS, high-frequency, and memory applications.
