FOPoP
In mobile and networking designs, every fraction of a millimeter of z-height and every picojoule per bit counts. Conventional interposer-based package-on-package (PoP) stacks two or more packages vertically to integrate functions in a small footprint, but the interposer adds height and limits electrical and thermal performance. ASE's Fan-Out Package-on-Package (FOPoP) replaces that interposer with a redistribution-layer (RDL) fan-out bottom package — cutting profile while raising bandwidth and energy efficiency for the markets that need both.
What Fan-Out Package-on-Package (FOPoP) Is
FOPoP, one of the core pillars of the VIPack™ platform, is an RDL-based PoP that combines a fan-out bottom package with a standard package mounted on top, using fine-pitch plated copper (Cu) posts for through-mold vertical interconnection. The fabrication flow mirrors conventional PoP, except the bottom package is built with an RDL-first fan-out process. Eliminating the interposer is what gives FOPoP its profile, electrical, and thermal advantages.
Mobile: Thinner, More Efficient, Ready for Chiplets
For the mobile market, FOPoP achieves an ultra-low profile with almost 40% reduction in height over substrate-based package-on-package structures — decisive in smartphones, wearables, and AR/VR designs where z-height budgets are measured in fractions of a millimeter. Beyond thickness, FOPoP improves electrical efficiency to deliver power benefits for advanced silicon nodes, maintains a stable dielectric constant (Dk) across a wide high-frequency range, and uses advanced materials that hold warpage in check at high temperature for good surface-mount yields. Its process roadmap also extends to both heterogeneous and homogeneous chiplet integration, so a mobile platform built on FOPoP today can scale toward multi-die designs tomorrow.
Networking: Bandwidth and Energy per Bit
The networking numbers are where FOPoP's value becomes concrete. Compared with conventional approaches, FOPoP reduces the electrical path by 3x and enables denser bandwidth by up to 8x, allowing engine bandwidth expansion up to 6.4 Tbps per unit. Just as important for data-center power budgets, it improves energy efficiency from 25 pJ/bit to 5 pJ/bit — a 5x gain — while controlling losses above the 10 GHz frequency range.
These properties make FOPoP a natural fit for co-packaged optics. It offers advanced integration of the photonic IC (PIC), controller chips, and a special pre-alignment structure for the laser, optics, and fiber array units, providing sub-micron accuracy through passive alignment that improves both optical coupling performance and assembly efficiency.
Applications: AP+Memory, ASIC+Antenna, EIC+PIC
FOPoP has become a promising 3D integration solution across three combinations: application processor (AP) plus memory for 4G/5G handsets; ASIC plus antenna-in-package for 5G; and electronic IC (EIC) plus photonic IC (PIC) for networking and co-packaged silicon photonics. In each, FOPoP addresses architectural and integration requirements that conventional PoP cannot — enabling next-generation application processors, mobile, automotive, antenna-in-package, and optical designs.
FOPoP in the VIPack™ Platform
As a fan-out pillar of VIPack™, FOPoP shares the platform with Fan-Out Chip-on-Substrate (FOCoS), FOCoS-Bridge, Fan-Out System-in-Package (FOSiP), and 2.5D/3D IC. ASE's Integrated Design Ecosystem™ (IDE) supports the co-design needed to optimize signal integrity, warpage, and power across these vertical-integration architectures.
Conclusion
FOPoP demonstrates that removing the interposer is not a compromise but an upgrade: 40% lower profile for mobile, 6.4 Tbps per unit and 5 pJ/bit for networking, and a clear path to chiplet and co-packaged-optics integration. As the world's largest outsourced semiconductor assembly and test (OSAT) provider, ASE delivers FOPoP from co-design through volume production — helping customers fit more system into less space, at lower energy per bit.
Explore FOPoP and the VIPack™ platform: See how ASE's fan-out package-on-package technology can slim and accelerate your next design at ase.aseglobal.com.
Frequently Asked Questions
Q: What is Fan-Out Package-on-Package (FOPoP)? A: FOPoP is an RDL-based package-on-package in ASE's VIPack™ platform that combines a fan-out bottom package with a standard top package, connected by fine-pitch plated copper posts for through-mold vertical interconnection. Removing the interposer lowers profile and improves electrical and thermal performance.
Q: How much thinner is FOPoP than conventional PoP? A: FOPoP achieves an ultra-low profile with almost 40% reduction in height over substrate-based package-on-package structures, which is decisive for smartphones, wearables, and AR/VR designs with tight z-height budgets.
Q: What bandwidth and energy efficiency does FOPoP deliver for networking? A: FOPoP reduces the electrical path by 3x and enables up to 8x denser bandwidth, supporting engine bandwidth up to 6.4 Tbps per unit, while improving energy efficiency from 25 pJ/bit to 5 pJ/bit and controlling losses above 10 GHz.
Q: Is FOPoP suitable for co-packaged optics? A: Yes. FOPoP integrates the photonic IC (PIC), controller chips, and a pre-alignment structure for laser, optics, and fiber arrays, providing sub-micron passive-alignment accuracy that improves optical coupling and assembly efficiency.
Q: What applications use FOPoP? A: Three main combinations — application processor (AP) plus memory for 4G/5G, ASIC plus antenna-in-package for 5G, and EIC plus PIC for networking and co-packaged silicon photonics.
