A Highly Integrated AiP Design for 6G Applications
ASE's D-band antenna-in-package (AiP) for 6G delivers a measured peak gain of 15.2 dBi at 142 GHz while occupying just 40% of the footprint of the previous design. Two numbers usually pull against each other in millimeter-wave (mmWave) antenna design — higher gain typically demands a larger aperture — so cutting size by more than half without sacrificing gain or bandwidth is the result worth leading with. In an ASE paper by Po-I Wu and colleagues, a magneto-electric (ME) dipole AiP achieves exactly that across the 134–158 GHz band, pointing to how 6G radios can shrink without giving up link performance.
Why D-Band Forces the Antenna Into the Package
6G is expected to reach widespread rollout around 2030, pushing carrier frequencies into the D-band (110–170 GHz) to unlock the wide bandwidths that high-capacity links require. At these frequencies, two physical realities reshape the design. Wavelengths shrink to roughly two millimeters, so the antenna itself becomes small enough to integrate directly into the IC package rather than sit as a discrete component on the board. And path loss climbs steeply, so every decibel lost in the interconnect between the transceiver and the antenna directly erodes range.
That combination is what makes AiP the mainstream approach for mmWave. By placing the antenna and the RF chip inside one package, ASE shortens the interconnect, reduces signal attenuation, and shrinks the system footprint — the same value AiP already delivers for 5G mmWave bands at 24, 28, and 39 GHz, now pushed up by roughly a factor of five in frequency.
The Design: A Magneto-Electric Dipole on BT Substrate
The core innovation is the choice of radiator. A magneto-electric dipole combines an electric dipole and a magnetic dipole in one element, producing stable radiation patterns and wide bandwidth — properties that matter when the usable band is tens of gigahertz wide. ASE's unit antenna measures 1.4 mm and is excited by a slot, a feed method that keeps the structure compact and compatible with multilayer substrate fabrication.
| Parameter | Value |
|---|---|
| Antenna type | Magneto-electric (ME) dipole AiP |
| Unit antenna size | 1.4 mm, slot-excited |
| Array configuration | 4×4, fed by a four-way power divider |
| Feed network | Substrate integrated waveguide (SIW) |
| Substrate | Four-layer BT-based substrate |
| Target band | D-band, 6G |
Scaling from one element to a 4×4 array introduces the hard part: distributing signal to sixteen elements at 140 GHz without losing it in the feed. ASE uses a four-way power divider together with substrate integrated waveguide (SIW) routing on a four-layer bismaleimide triazine (BT) substrate. SIW behaves like a waveguide built inside the laminate, giving lower loss than conventional microstrip at these frequencies while remaining a standard, manufacturable substrate process rather than an exotic one.
Measured Results: Gain Held, Side Lobes Cut, Size Halved
The unit antenna simulated a 27 GHz bandwidth from 125 to 152 GHz with a 7.6 dBi peak gain. The fabricated 4×4 array then measured the figures that matter for a real radio:
| Metric | Unit antenna (simulated) | 4×4 array (measured) |
|---|---|---|
| Bandwidth | 27 GHz (125–152 GHz) | 24 GHz (134–158 GHz) |
| Peak gain | 7.6 dBi | 15.2 dBi at 142 GHz |
| Average gain | — | 14.6 dBi |
| Side lobe level (SLL) | — | 12.2 dB |
Two results stand out against prior ASE work. The side lobe level improved by 7.3 dB for the 2×2 array and 4.9 dB for the 4×4 array — lower side lobes mean more radiated energy goes toward the intended direction and less leaks into interference, which is decisive for beam-steered 6G links. And the whole design occupies only 40% of the area of the previous version while holding a comparable 134–158 GHz bandwidth and 15.2 dBi peak gain. Simulation and measurement agreed closely, which gives the result engineering credibility rather than a one-off lab number.
Where This Fits in ASE's mmWave Platform
ASE develops AiP through its leadership in system-in-package (SiP) technology, offering a full path from system design and software development through module testing and electro-thermal simulation. The same SiP toolbox that builds this 6G antenna — double-side molding, selective molding, passive integration, and electromagnetic interference (EMI) shielding — already produces 5G mmWave transceiver modules and standalone AiP that integrate the RF transceiver IC, power management IC, antenna array, and passives in one package.
This D-band design extends a multi-year AiP research line at ASE that spans dual-band 28/39 GHz antennas for 5G mmWave and antennas with double-layer parasitic elements. Each generation has pushed frequency higher and footprint lower; the D-band ME dipole is the current step toward 6G-ready integration.
What Comes Next
A D-band AiP that pairs 15.2 dBi gain with a 40% smaller footprint and lower side lobes gives 6G system designers a building block for compact, high-frequency radios where board area is scarce and link budgets are tight. As 6G standards firm up toward the end of the decade, the combination of a manufacturable BT substrate, SIW feed networks, and ASE's SiP integration capability offers a production-oriented path rather than a research curiosity — the difference between a published antenna and one that ships inside a phone or base station.
Designing for mmWave or 6G? See how ASE's antenna-in-package and SiP solutions integrate RF transceivers and antenna arrays at ase.aseglobal.com.
Frequently Asked Questions
Q: What is an antenna-in-package (AiP)? A: An antenna-in-package implements the antenna inside the IC package alongside the RF transceiver chip, instead of placing it as a separate component on the board. At millimeter-wave (mmWave) frequencies, AiP shortens the interconnect between antenna and chip, reduces signal attenuation, and shrinks the system footprint — which is why it is the mainstream antenna technology for 5G and 6G mmWave.
Q: What is a magneto-electric (ME) dipole antenna and why use it for 6G? A: A magneto-electric dipole combines an electric dipole and a magnetic dipole in one radiating element, producing stable radiation patterns and wide bandwidth. Those properties suit D-band 6G, where the usable band is tens of gigahertz wide. ASE's ME dipole unit antenna measures 1.4 mm and is slot-excited.
Q: What gain and bandwidth did ASE's 6G AiP achieve? A: The 4×4 array measured a peak gain of 15.2 dBi at 142 GHz, an average gain of 14.6 dBi, and a 24 GHz bandwidth from 134 to 158 GHz, with a side lobe level of 12.2 dB. The simulated unit antenna covered 125–152 GHz with a 7.6 dBi peak gain.
Q: How much smaller is this 6G antenna than the previous design? A: The overall design occupies only 40% of the area of the previous version while maintaining comparable 134–158 GHz bandwidth and a 15.2 dBi peak gain. It also reduces the side lobe level by 7.3 dB in the 2×2 array and 4.9 dB in the 4×4 array compared with prior work.
Q: What is substrate integrated waveguide (SIW) and why does it matter at D-band? A: SIW is a waveguide formed inside a laminate substrate using rows of vias, behaving like a metal waveguide while remaining a standard, manufacturable substrate process. At D-band frequencies it offers lower loss than conventional microstrip feed lines, which helps preserve the array's gain when distributing signal to sixteen elements.
