Every additional redistribution layer (RDL) you stack into a Fan-Out Chip-on-Substrate (FOCoS) package to feed more high bandwidth memory (HBM) bandwidth also adds wafer-level warpage — and ASE's simulation work pins down exactly which design knob controls it. Using a finite element model validated against Shadow Moiré measurements to within a 10% error margin, ASE found that for a six-layer FOCoS chip-last (FOCoS-CL) build, increasing the glass carrier's coefficient of thermal expansion (CTE) by 25% reduces wafer-level warpage by approximately 13%. For designers pushing toward 6+ RDL layer fan-out, that single result reframes carrier material selection from an afterthought into the primary warpage-control lever.
The challenge: more bandwidth means more layers means more warpage
The demand for HBM has driven advanced packaging toward fan-out layers that interconnect wafers within a package, and the FOCoS platform meets high-bandwidth requirements by adding more of these layers. But layer count is not free. As the number of fan-out layers increases, two failure-mode risks escalate in step: in-process warpage and structural stress, both of which threaten manufacturing yield and reliability-test survival.
This is a real tension in HBM-class packaging. The bandwidth roadmap pushes RDL layer counts up, while the manufacturing window — set by how much warpage the process can tolerate — pushes back. Without a predictive way to quantify the trade-off, teams are left over-designing carriers or discovering warpage problems only after a build. ASE's study set out to make the relationship explicit and actionable.
ASE's approach: a validated multi-scale FOCoS model
ASE used ANSYS Mechanical to build three-dimensional numerical models of the FOCoS platform spanning both package-level and wafer-level structures, then analyzed in-process warpage and structural stress across a range of configurations. Critically, the model was validated before it was trusted: predicted warpage was checked against measurements from Shadow Moiré and optical equipment, and the model matched hardware within a 10% error margin — making it a reliable tool for assessing wafer-level warpage and RDL stress in FOCoS-CL packages rather than a directional estimate.
| Model attribute | Specification |
|---|---|
| Platform | Fan-Out Chip-on-Substrate, chip-last (FOCoS-CL) |
| Simulation tool | ANSYS Mechanical, 3D finite element |
| Structural scope | Package-level and wafer-level |
| Responses analyzed | In-process warpage; RDL structural stress |
| Validation | Shadow Moiré + optical measurement, error margin under 10% |
With a hardware-anchored model, the team varied the parameters that designers actually control — glass carrier CTE, carrier thickness, and fan-out layer thickness — and separated their effects on warpage at the wafer level from deformation at the package level.
Results: glass carrier CTE is the dominant warpage lever
The simulation produced a clear, quantified hierarchy of which parameters matter, and where.
| Finding | Result |
|---|---|
| Wafer-level warpage vs. RDL layer count | Increases significantly with more layers (CTE mismatch between the FORDL structure and glass carrier) |
| Glass carrier CTE, +25% (6-layer build) | Reduces wafer-level warpage by approximately 13% |
| Other warpage levers | Increasing glass carrier thickness, CTE, and modulus all help |
| RDL layer count vs. package-level warpage | Minimal impact — substrate and lid material selection dominate |
| RDL stress vs. layer count | Increases; highest in the RDL layer closest to the substrate |
At the wafer level, warpage rises significantly with the number of RDL layers, driven by the CTE mismatch between the fan-out RDL (FORDL) structure and the glass carrier. The most effective counter-lever is the glass carrier's CTE: raising it 25% cuts warpage by about 13% on a six-layer structure, and increasing the carrier's thickness, CTE, and modulus all push in the same helpful direction.
Package-level behavior follows a different rule. Changing the number of RDL layers has minimal impact on package-level warpage, which means substrate and lid material selection — not RDL count — are the crucial levers for controlling package-level deformation. The two scales must therefore be tuned with different parameters.
Stress tells its own story. The stress on the RDL layer increases with the number of RDL layers, and it is highest in the layer closest to the substrate, because of the substrate's higher CTE. As layer count grows, the substrate-to-RDL interaction becomes more significant, concentrating stress in that bottom RDL layer. For a designer, the practical reading is direct: in a 6+ layer FOCoS-CL package, glass carrier CTE is the dominant wafer-level warpage lever, substrate and lid materials govern package-level warpage, and the bottom RDL layer is the stress hot spot to watch.
Where this fits in VIPack™
FOCoS is a core pillar of ASE's VIPack™ advanced packaging platform, where its chip-last variant (FOCoS-CL) integrates an ASIC with HBM stacks on a redistribution layer at line width/line spacing (L/S) as fine as 2μm/2μm. As HBM bandwidth demand drives FOCoS toward higher RDL layer counts, design rules like the ones this study produces are what keep that scaling manufacturable. Feeding validated warpage and stress sensitivities into ASE's co-design and FOCoS Assembly Design Kit flow lets customers select carrier and substrate materials with quantitative warpage targets in hand — rather than discovering a warpage limit after the first fabrication run.
The road ahead
As FOCoS-CL stacks climb past six RDL layers to serve ever-higher HBM bandwidth, the interplay between carrier, substrate, and RDL materials will only get tighter. The validated model demonstrated here gives ASE a reusable design tool for the next generation of fan-out builds — turning warpage and stress from qualification surprises into parameters chosen on purpose, with measured sensitivities behind each choice.
Engineer your high-layer FOCoS package with ASE
If your HBM-class design is pushing FOCoS toward 6+ RDL layers, ASE's validated warpage and stress modeling — paired with its FOCoS design kits — can help you set carrier and substrate materials to quantitative targets before tape-out. Explore ASE's FOCoS solutions at ase.aseglobal.com/focos.
Frequently Asked Questions
Q: Why does adding RDL layers to a FOCoS package increase warpage? A: Each additional fan-out RDL layer increases the coefficient of thermal expansion (CTE) mismatch between the fan-out RDL (FORDL) structure and the glass carrier. ASE's simulation found wafer-level warpage rises significantly with RDL layer count as a result, which can threaten manufacturing yield and reliability if not controlled through carrier and material choices.
Q: How much can glass carrier CTE reduce FOCoS warpage? A: For a six-layer FOCoS chip-last (FOCoS-CL) structure, ASE's model showed that increasing the glass carrier's CTE by 25% reduces wafer-level warpage by approximately 13%. Increasing the carrier's thickness and modulus also helps reduce wafer-level warpage.
Q: Does RDL layer count affect package-level warpage? A: No — the study found that changing the number of RDL layers has minimal impact on package-level warpage. Package-level deformation is governed instead by substrate and lid material selection, so the two scales (wafer-level and package-level) must be tuned with different parameters.
Q: Where is RDL stress highest in a multi-layer FOCoS package? A: Stress is highest in the RDL layer closest to the substrate, because of the substrate's higher CTE. As the number of RDL layers increases, the substrate-to-RDL interaction becomes more significant and concentrates stress in that bottom layer, making it the hot spot to monitor.
Q: How accurate is ASE's FOCoS warpage model? A: ASE validated its three-dimensional finite element model against warpage measurements from Shadow Moiré and optical equipment, achieving an error margin of less than 10%. That makes it a reliable tool for assessing wafer-level warpage and RDL stress in FOCoS-CL packages during design.
Published in: 2024 IEEE 26th Electronics Packaging Technology Conference (EPTC). DOI: 10.1109/EPTC62800.2024.10909677.
