Reliability Prediction and Improvement of Board-Level Thermal Cycling Test for Molded Flip-Chip Ball-Grid-Array Package
A board-level thermal cycling test (BL-TCT) can run for months before it tells you whether a solder joint will survive the field — and by then the design is frozen and the schedule is spent. An ASE team led by Dao-Long Chen attacked that problem at the 2023 IEEE 25th Electronics Packaging Technology Conference (EPTC) by borrowing the digital-twin idea: pair a simulated model with real tests to build a lifecycle prediction curve for a molded flip-chip ball-grid-array (MFCBGA) package, predict reliability before the physical test finishes, and use the same model to improve it. The reported accuracy is within ±15%, and the structural and material changes the team studied improved BL-TCT life by up to 33%.
Why Board-Level Thermal Cycling Is a Schedule Problem
Every package soldered to a board lives through temperature swings, and each swing strains the solder joints because the package and the printed circuit board expand at different rates. BL-TCT reproduces that stress by cycling parts between temperature extremes until joints crack, and it is the standard way to qualify solder-joint reliability. The catch is time: thermal cycles accumulate slowly, so a full BL-TCT campaign can dominate a product's qualification schedule. When the result finally arrives, a marginal design has already cost months — and fixing it means another cycle of build-and-test.
The MFCBGA package this study targets is a flip-chip ball-grid-array (FCBGA) with overall molding — molding that protects the die, can substitute for underfill, and improves thermal and second-level reliability. Its board-level solder joints, formed with SAC305 (a tin-silver-copper alloy), are exactly the joints BL-TCT stresses. The question the team set out to answer is whether those joints' lifetime can be predicted before the test ends, rather than discovered after.
ASE's Approach: A Digital Twin Built on Morrow and Anand
The method follows the digital-twin spirit: a virtual model (CAE simulation) and a physical model (real tests) are used together to construct a single lifecycle prediction curve for the MFCBGA with SAC305 solder balls. Neither model stands alone — the simulation is anchored to measured data, and the measured data is extended by simulation into a predictive curve.
| Modeling element | What it does | Role in the prediction |
|---|---|---|
| Digital twin (virtual + physical) | CAE simulation paired with real BL-TCT data | Builds one lifecycle prediction curve |
| Morrow's energy-based model | Fits data points from both virtual and physical models | Relates dissipated energy per cycle to fatigue life |
| Anand viscoplastic model | Describes SAC305 plastic and creep behavior | Captures how solder deforms under thermal stress |
| Validation scope | One package type, one temperature condition, one solder type | Accuracy reported within ±15% |
Two material models do the physics. The energy-based Morrow model fits the data points from both the virtual and physical models — it ties the strain energy dissipated in the solder each cycle to the number of cycles to failure, the standard energy approach to solder fatigue. Underneath it, the viscoplastic Anand model describes the SAC305 material's plastic and creep effects, so the simulation reproduces how the solder actually deforms and relaxes as temperature swings. With both in place, the team reports a lifecycle prediction accuracy within ±15% — and they are explicit about the scope of that number: it holds for the one package type, the one temperature condition, and the one solder type studied. That discipline matters; the ±15% is a validated result inside a defined window, not a blanket claim.
From Prediction to Improvement: Up to 33% Longer Life
A prediction curve is only half the value. Once the model can estimate a new device's reliability ahead of the real test, it changes the workflow on both outcomes. If the predicted reliability is good, the physical BL-TCT can be reduced or skipped — saving the cost and schedule that the full campaign would have consumed. If the predicted reliability is not good, the CAE model becomes a design tool: the team can investigate which material and structural choices move the lifetime, before committing to a build.
That is what the study did. By investigating material and structural effects in simulation, the team identified changes that improved the BL-TCT result by up to 33%. The improvement comes from the model pointing at the right variables — not from running more physical cycles. For a package designer, that is the difference between discovering a reliability shortfall at the end of qualification and engineering it out at the modeling stage.
What This Means for a Customer Qualifying a Package
For a customer bringing an MFCBGA-class package to qualification, a ±15% lifecycle model reshapes the risk and the calendar. A device the model predicts as robust can move forward with reduced physical testing, compressing the qualification window that BL-TCT normally stretches out. A device the model flags as marginal can be improved before a single test board is built — and the demonstrated 33% headroom shows the model is sensitive enough to the right design levers to make that improvement real, not theoretical.
It also concentrates engineering effort where it pays. Instead of spending months of thermal cycling to learn a joint is weak, a designer spends simulation time understanding why and fixing it. For high-volume parts, where a reliability miss caught late can stall a ramp, a validated digital twin moves the decision point forward to where changes are cheap.
Where This Fits in ASE's Reliability and Digital-Twin Work
This study is part of a broader ASE move to put digital twins between simulation and the test floor. The same team's work on underfill dispensing uses the identical philosophy — replacing slow, costly physical trials with a validated virtual model — and ASE's wider reliability portfolio spans the stress, thermal, and material labs that generate the measured data these models are anchored to. Because ASE develops the package, runs the BL-TCT, and builds the CAE model in-house, the loop from prediction to physical confirmation to design change stays inside one organization.
A lifecycle model is only as trustworthy as the data behind it, which is why the explicit ±15% scope matters: it is a calibrated tool for a defined package, temperature, and solder system, with a clear path to extend as more conditions are measured. That is the disciplined foundation reliability engineering needs.
What Comes Next
As packages grow more complex and qualification timelines tighten, predicting solder-joint reliability before the test finishes becomes less a convenience than a requirement. A digital twin built on Morrow and Anand models, validated to within ±15% and already shown to find up to 33% of life improvement, is a dependable way to get there. By predicting BL-TCT outcomes ahead of time and using the same model to improve them, ASE helps its customers qualify reliable packages faster — and fix the marginal ones before they reach a test board.
Need to qualify a flip-chip BGA package faster without compromising reliability? Explore ASE's packaging and reliability capabilities at ase.aseglobal.com.
Frequently Asked Questions
Q: What is a board-level thermal cycling test (BL-TCT)? A: A board-level thermal cycling test cycles a board-mounted package between temperature extremes to stress its solder joints, which fatigue because the package and the printed circuit board expand at different rates. It is the standard way to qualify solder-joint reliability — but a full campaign accumulates cycles slowly and can dominate a product's qualification schedule, which is why predicting the outcome in advance is valuable.
Q: How does ASE predict MFCBGA reliability before the test finishes? A: ASE uses a digital twin: a CAE simulation (virtual model) paired with real test data (physical model) builds a single lifecycle prediction curve for the molded flip-chip ball-grid-array (MFCBGA) package with SAC305 solder. An energy-based Morrow model fits the data and a viscoplastic Anand model captures the solder's plastic and creep behavior, giving a lifecycle prediction accurate to within ±15% for the studied package, temperature, and solder type.
Q: What are the Morrow and Anand models? A: The energy-based Morrow model relates the strain energy dissipated in the solder per thermal cycle to the number of cycles to failure — the standard energy approach to solder fatigue. The viscoplastic Anand model describes how the SAC305 solder deforms plastically and creeps under thermal stress. Used together, they let the simulation reproduce real solder-joint fatigue behavior.
Q: How much can the reliability be improved? A: By investigating material and structural effects within the validated model, ASE identified changes that improved the BL-TCT result by up to 33%. Because the model points to the right design variables, the improvement is engineered at the simulation stage rather than discovered through additional physical thermal cycling.
Q: Why does the ±15% accuracy come with conditions? A: The ±15% accuracy is a validated result for one package type, one temperature condition, and one solder type — not a universal claim. Stating that scope is part of good data discipline: the model is a calibrated tool inside a defined window, with a clear path to extend its validity as more package, temperature, and solder conditions are measured.
