Electrical Performance Analysis for Bridge Die Package Solution

A silicon bridge only earns its place in an AI or networking package if the signal it carries arrives clean — and the only way to promise that to a customer is to show that simulation predicts measured behavior. In a 2022 International Conference on Electronics Packaging (ICEP) paper, an ASE team led by Po Chih Pan does exactly that for a bridge die package built on two redistribution layers (RDL): they analyze the routing design patterns, run signal integrity (SI) simulation, measure the S-parameters on real hardware, and report a good correlation between the two. That correlation is the headline result, because a validated SI model is what lets designers commit a bridge die architecture to a high-bandwidth product with confidence.

Why Bridge Die Packages Need a Validated SI Model

High-performance products — 5G mobile communication, network servers, and artificial intelligence (AI) accelerators — all push in the same direction: more data, higher data rates, and broader bandwidth. Meeting that demand means moving signals between dies faster and across more channels than a conventional organic package can comfortably support. The die-to-die (D2D) interconnect becomes the bottleneck.

The bridge die package addresses that bottleneck. ASE's Fan-Out Chip-on-Substrate-Bridge (FOCoS-Bridge) embeds a small silicon bridge die — with its own ultra-fine routing layers — inside the fan-out RDL to connect two chiplets, such as an ASIC and a high bandwidth memory (HBM) stack. The bridge provides silicon-grade interconnect density only in the small region where two dies meet, delivering 2.5D-class D2D bandwidth without the cost and reticle-size constraints of a full silicon interposer.

But density is only half the promise. At the data rates these applications run, the interconnect's electrical behavior — insertion loss, return loss, crosstalk, impedance — determines whether the link actually closes. Before a customer commits a design, they need to know that the package will behave the way the model says it will. That is the gap this paper closes: it establishes that ASE's SI simulation of a bridge die package matches what the hardware actually does.

ASE's Approach: Two RDL Layers, Routing Patterns, Measurement vs. Simulation

The study analyzes a bridge die package built on two RDL layers, examining its electrical performance through the routing design patterns used to interconnect the dies. Rather than treating the package as a single black box, the team looks at how specific routing patterns across the two RDL layers shape the signal path — the practical variable a package designer actually controls.

Study element	Detail	Engineering purpose
Package architecture	Bridge die package (FOCoS-Bridge class)	Silicon-bridge D2D interconnect between chiplets
RDL stack analyzed	Two RDL layers	Realistic routing budget for D2D signals
Design variable	Routing design patterns	Isolate how layout choices affect SI
Validation method	S-parameter measurement + SI simulation	Cross-check model against hardware
Key outcome	Good correlation (measurement vs. simulation)	Establishes a trustworthy design model

The validation uses S-parameters — the standard frequency-domain description of how a signal is transmitted and reflected through an interconnect. The team performs both the S-parameter measurement on fabricated hardware and the corresponding SI simulation, then compares them. The reported result is a good correlation between measured and simulated S-parameters on the bridge die package platform.

Specific S-parameter values, the frequency range of the correlation, and the exact routing pattern dimensions are detailed in the original ICEP paper [TBD - 待確認]; ASE's knowledge base does not restate these figures, and they are not reproduced here to avoid fabricating data.

What the Correlation Means for a Package Designer

A good measurement-to-simulation correlation is not an academic nicety — it is the license to design. Once a designer knows that ASE's SI model reproduces measured S-parameters for a two-RDL-layer bridge die package, they can iterate routing patterns in simulation and trust the answer, instead of waiting for a fabricated test vehicle to learn whether a layout closes timing. That compresses the design loop: routing trade-offs that would otherwise require a silicon spin can be resolved at the modeling stage.

It also de-risks the platform choice. For a customer weighing FOCoS-Bridge against a silicon interposer for an AI accelerator or networking ASIC, the question is always whether the lower-cost bridge approach can carry the same signal quality. A validated SI model answers that question with the customer's own routing patterns, on ASE's actual two-RDL-layer stack — turning "the bridge should work" into "the bridge is modeled and measured to work." For high-bandwidth designs where every channel counts, that confidence is what moves a design from evaluation to commitment.

Where This Fits in ASE's FOCoS-Bridge Roadmap

This electrical validation sits at the foundation of ASE's FOCoS-Bridge offering within the VIPack™ advanced packaging platform. FOCoS-Bridge is positioned as a lower-cost, reticle-unconstrained alternative to 2.5D silicon interposers, delivering submicron-class bridge routing and high-density D2D interconnect for AI and high-performance computing (HPC). The bridge die itself carries the finest routing — on the order of 0.6μm/0.6μm L/S in ASE's FOCoS-Bridge test vehicles — embedded within a coarser fan-out RDL, while the package-level RDL routing analyzed in this paper carries the signals out to the substrate.

Establishing SI model fidelity at the two-RDL-layer level is the groundwork that later, more aggressive FOCoS-Bridge generations build on — including versions that add through silicon via (TSV) structures for improved power delivery. Each step up in bandwidth and complexity depends on the same discipline this paper demonstrates: measure, simulate, and prove the two agree before scaling.

Because ASE develops the bridge die process, the fan-out RDL, the package design kits, and the in-house S-parameter measurement capability together, a validated SI workflow can be folded directly into the design enablement ASE offers customers through its Integrated Design Ecosystem™ — shortening the path from D2D architecture to a qualified, high-bandwidth package.

What Comes Next

As AI and networking bandwidth requirements keep climbing, the bridge die package will carry more channels at higher data rates, and the margin for SI error will keep shrinking. A measurement-validated simulation model for the two-RDL-layer bridge die package is the dependable starting point for that scaling. By proving that simulation predicts measured S-parameters, ASE gives its customers a design model they can push, confident that the signal will arrive the way the model says it will.

Evaluating a bridge die or FOCoS-Bridge architecture for your high-bandwidth design? Explore ASE's FOCoS-Bridge capabilities at ase.aseglobal.com.

Frequently Asked Questions

Q: What is a bridge die package? A: A bridge die package embeds a small silicon bridge die — carrying its own fine routing layers — inside the package to connect two chiplets, such as an ASIC and a high bandwidth memory (HBM) stack. ASE's Fan-Out Chip-on-Substrate-Bridge (FOCoS-Bridge) places the silicon bridge only in the region where two dies meet, delivering 2.5D-class die-to-die (D2D) interconnect density without the cost and reticle-size limits of a full silicon interposer.

Q: Why analyze electrical performance with S-parameters? A: S-parameters describe, in the frequency domain, how a signal is transmitted and reflected through an interconnect — capturing insertion loss, return loss, and impedance behavior. For a high-bandwidth bridge die package, these are exactly the metrics that determine whether a high-speed link closes, which is why the paper uses S-parameter measurement and simulation to evaluate the package.

Q: What did the measurement-to-simulation correlation show? A: The study performed both S-parameter measurement on fabricated hardware and signal integrity (SI) simulation of a two-RDL-layer bridge die package, then compared them and reported a good correlation between the two on the bridge die package platform. This establishes that ASE's SI model reliably predicts the package's measured electrical behavior.

Q: Why does a validated SI model matter to designers? A: When simulation reliably reproduces measured results, designers can iterate routing design patterns in software and trust the outcome instead of waiting for a fabricated test vehicle. This compresses the design loop, lets routing trade-offs be resolved before silicon, and de-risks choosing a bridge die architecture over a more expensive silicon interposer.

Q: How does the bridge die package serve AI, 5G, and server applications? A: These applications demand large data transmission, higher data rates, and broader bandwidth, which stresses the die-to-die interconnect. The bridge die package provides silicon-grade D2D density where chiplets connect, supporting the bandwidth these workloads need while remaining more cost-effective and scalable than a full silicon interposer.
