Enabling Next-generation System Integration with Scalable SiP Solutions for Healthcare Applications

A wafer-level system-in-package (SiP) sensor can occupy 30% less XY area than a traditional quad flat no-lead (QFN) package while cutting electrical resistance by almost 80% — and in medical devices, that combination of smaller footprint and cleaner signal is the difference between a wearable a patient will tolerate and one they will not. Semiconductor miniaturization and chip-integration trends have pushed the industry toward SiP precisely because it delivers higher performance and shorter time-to-market in one cost-effective package. For healthcare applications, where reliability and form factor both matter, ASE's scalable SiP solutions are becoming the integration backbone.

Continuous Glucose Monitors: Integration Without Compromise

A continuous glucose monitor (CGM) is a small, body-worn device that tracks blood-sugar levels through the day and surfaces trends and patterns a periodic finger-stick would miss. The packaging challenge is that a CGM has to coordinate several distinct functions — sensing, control, and wireless reporting — inside a footprint small enough to wear discreetly for days at a time.

ASE's SiP technology supports the integration of microcontrollers (MCUs), application-specific integrated circuits (ASICs), antennas, and sensors that control all CGM functions onto a single package structure. Consolidating those blocks into one module delivers the miniaturization a wearable CGM demands without compromising device performance — the radios still reach, the sensor still reads, and the control logic still runs, all in a fraction of the board area a discrete design would require.

In Vitro Diagnostics: Molding Around Microfluidics

In vitro diagnostics (IVD) are tests performed on samples taken from the body — mucus or blood — to detect diseases or conditions. Unlike a CGM, an IVD module has to combine electronics with fluid handling, which is a harder packaging problem because the two domains have incompatible requirements.

SiP processes make complex IVD module designs possible by integrating bio-sensor chips together with microfluidic receptacles through customized molding techniques. The molding step is what bridges the electronic and fluidic worlds: it forms the channels and cavities that route a sample to the sensor while protecting the silicon, so a single package can both move the fluid and read the result. That integration is what lets IVD shrink from benchtop instruments toward point-of-care and portable formats.

Wafer-Level SiP for Sensors and Sensor Hubs

The biggest gains come at the wafer level. For sensor applications, wafer-level SiP applies through silicon via (TSV) chip-scale package (CSP) processes to reduce XY area by 30% compared with traditional QFN packaging, while enhancing electrical performance by lowering resistance level by almost 80%. Lower resistance directly improves signal quality from the low-amplitude bio-signals these sensors capture — a smaller package that also measures more accurately.

Sensor hubs raise the integration further. A sensor hub is a microcontroller unit that aggregates and processes data from multiple sensors, and ASE designs the chips inside them using through silicon via (TSV) and chip-to-wafer (C2W) bonding. Applied to 3D inertial, gas, temperature, and humidity sensors, wafer-level SiP reduces package sizes by 25% to 77% compared with traditional packaging processes — a range wide enough to fit the same sensing capability into devices from wrist-worn monitors to ingestible or implantable formats.

Healthcare SiP technique	Baseline	Result
Wafer-level SiP, TSV CSP (sensors)	Traditional QFN	30% smaller XY area; ~80% lower resistance
Wafer-level SiP (sensor hubs)	Traditional packaging	25%–77% smaller package size
SiP module (CGM)	Discrete components	MCU + ASIC + antenna + sensor on one package

A Scalable, Turnkey SiP Platform

What makes these techniques usable in a regulated medical-device pipeline is that they are scalable across a complete service flow. ASE provides the full suite — package design, functional simulation, testing, verification, volume production, and final testing — under one roof. For a medical-device maker, that turnkey path matters as much as any single specification: it shortens the qualification cycle that dominates healthcare time-to-market and keeps design, build, and test accountable to one partner rather than fragmented across vendors.

Scalability is also why these are not one-off solutions. The same wafer-level SiP, TSV, and C2W building blocks that miniaturize a CGM apply to IVD modules, sensor hubs, and the next generation of medical sensors, so a customer can move up the integration curve without re-architecting from scratch.

Where Healthcare SiP Goes Next

Medical electronics are following the same trajectory as consumer wearables — more sensing, more autonomy, smaller form factors — but with a higher bar for reliability and signal fidelity. The TSV and wafer-level SiP techniques that deliver 30% smaller sensors and 25%–77% smaller sensor hubs are what keep that trajectory viable as devices move closer to, and eventually inside, the body. As the world's largest outsourced semiconductor assembly and test (OSAT) provider, ASE continues to deliver scalable, industry-leading SiP integration that helps healthcare customers accelerate product development from package design through volume production.

Developing a medical sensor or diagnostic device? See how ASE's scalable SiP, TSV, and wafer-level integration can take your healthcare product from design to volume production at ase.aseglobal.com.

Frequently Asked Questions

Q: Why is system-in-package (SiP) used in healthcare and medical devices? A: SiP is a cost-effective integration technology that delivers higher performance and shorter time-to-market by combining sensing, control, and connectivity into one small module. For medical devices, that enables the miniaturization and reliability needed for body-worn and point-of-care formats.

Q: How does SiP enable continuous glucose monitors (CGMs)? A: ASE's SiP integrates the microcontrollers (MCUs), application-specific integrated circuits (ASICs), antennas, and sensors that control all CGM functions onto a single package structure, achieving the miniaturization a wearable CGM needs without compromising device performance.

Q: How much smaller is wafer-level SiP than traditional QFN packaging? A: For sensor applications, wafer-level SiP using through silicon via (TSV) chip-scale package (CSP) processes reduces XY area by 30% compared with traditional quad flat no-lead (QFN) packaging, while lowering electrical resistance by almost 80% to improve signal quality.

Q: How does SiP support in vitro diagnostics (IVD)? A: SiP processes integrate bio-sensor chips with microfluidic receptacles through customized molding techniques, forming the channels that route a sample to the sensor while protecting the silicon — which enables complex IVD modules to shrink toward portable, point-of-care formats.

Q: How much can wafer-level SiP shrink a sensor hub? A: Using through silicon via (TSV) and chip-to-wafer (C2W) bonding, wafer-level SiP applied to 3D inertial, gas, temperature, and humidity sensors reduces package sizes by 25% to 77% compared with traditional packaging processes.
