Integration of Foundry MIM Capacitor and OSAT Fan-Out RDL for High Performance RF Filters

A 5G FR1 band-pass filter has to handle real transmit power without distorting, and the conventional integrated passive device (IPD) tops out around 36 dBm of sustainable input power. By combining a foundry metal-insulator-metal (MIM) capacitor with outsourced semiconductor assembly and test (OSAT) Fan-Out redistribution layer (RDL) inductors, an ASE team led by Pao-Nan Lee pushes an 800 MHz low-pass filter (LPF) test vehicle to at least 38 dBm — and demonstrates working n77 and n79 band-pass filters at 1.44 dB and 2.07 dB insertion loss. The structure does more than improve a filter: because Fan-Out RDL can replace the conventional coreless packaging substrate, it also yields a thinner RF front-end module (FEM). The work was published at the 2022 IEEE 72nd Electronic Components and Technology Conference (ECTC).

Why 5G FR1 Bands Break Conventional Filter Design

5G has been deployed at scale since 2020, and the FR1 sub-6GHz range carries much of that traffic. Three bands — n77, n78, and n79 — are the critical ones, and they are demanding precisely because they sit at higher frequency and far wider bandwidth than legacy cellular bands. A filter that has to pass a wide band cleanly while rejecting everything outside it, all at elevated transmit power, stresses every element in the filter network.

The pinch point is the passive components. A filter is built from inductors and capacitors, and their quality factor (Q), power handling, and parasitics set how sharp the filter's skirts are and how much loss it adds in the pass band. Conventional IPD filters integrate these passives on a silicon process, but they run into a power-handling ceiling — around 36 dBm of sustainable input power in this comparison — that constrains how they can be used in a 5G transmit path. To raise both performance and power handling, the passive structure itself has to change.

ASE's Approach: Foundry MIM Capacitors Meet OSAT Fan-Out RDL Inductors

The core idea is a division of labor across two manufacturing domains. The capacitor — where a foundry's metal-insulator-metal (MIM) process delivers high capacitance density and tight tolerance — comes from the foundry. The inductor — where loop area and conductor thickness drive Q — is built in the OSAT's Fan-Out RDL, whose routing geometry can be tuned for inductor performance. ASE combines the two into one filter structure, pairing each passive with the process best suited to make it well.

Filter / metric	Conventional IPD	ASE MIM + Fan-Out RDL structure
800 MHz LPF — sustainable input power	36 dBm	at least 38 dBm
n77 band-pass filter — insertion loss	—	~1.44 dB
n79 band-pass filter — insertion loss	—	~2.07 dB
n77 / n79 — max sustainable input power	—	34 dBm (both)
Module structure	Coreless packaging substrate	Fan-Out RDL replaces substrate → thinner RF FEM

The results validate the approach across two filter types. The 800 MHz LPF test vehicle sustains at least 38 dBm, exceeding the 36 dBm of the conventional IPD — a direct power-handling gain. Building on that, the team designed and fabricated band-pass filters for n77 and n79: insertion loss measured approximately 1.44 dB for n77 and 2.07 dB for n79, with maximum sustainable input power of 34 dBm for both filters. These are not projections; they are fabricated-and-measured results on real test vehicles.

What This Structure Means for an RF Front-End Designer

For an RF front-end designer, the headline is that this structure lifts the power-handling ceiling while keeping insertion loss low — the two specifications that usually trade against each other. A filter that sustains at least 38 dBm where the conventional IPD sustained 36 dBm gives the transmit chain more margin before compression, which matters directly in a 5G FR1 power amplifier path where every decibel of headroom affects linearity and efficiency. Pass-band insertion loss of 1.44 dB at n77 keeps the link budget healthy, because loss in the filter is power the antenna never radiates.

The second benefit is structural, and it reaches beyond the single filter. Because the Fan-Out RDL can replace the conventional coreless packaging substrate, the same technology that makes the filter also thins the RF front-end module that houses it. For a smartphone or a compact 5G radio where z-height and board area are scarce, folding the filter passives into the RDL stack instead of mounting discrete IPDs on a substrate removes a layer of the module's thickness — and consolidates the bill of materials at the same time.

Where This Fits in ASE's Fan-Out SiP and RF Capability

This filter structure is a concrete instance of ASE's broader Fan-Out System-in-Package (FOSiP) strategy: use the Fan-Out RDL not just as interconnect, but as an active substrate for tuning system performance. ASE's FOSiP platform already provides finer RDL line width/line spacing than mainstream substrates — supporting roughly a 5x enhancement in design control and around a three-layer substrate reduction — along with wafer-level assembly and optional five-side shielding for RF applications. Embedding high-Q RDL inductors for filters is exactly the kind of performance tuning that platform is built to enable.

It also reflects how ASE works across the supply chain. Pairing a foundry MIM capacitor with OSAT Fan-Out RDL inductors is a heterogeneous integration play — combining components made by the most suitable process technology into one optimized structure. Because ASE provides the Fan-Out RDL process, the assembly, the RF measurement capability, and the design support together, an RF FEM built this way can move from a filter test vehicle toward a manufacturable module within one turnkey flow.

What Comes Next

As 5G FR1 deployment broadens and front-end modules face tighter power, loss, and form-factor budgets, integrating passives into the package rather than mounting them discretely becomes the path forward. A filter structure that pairs foundry MIM capacitors with OSAT Fan-Out RDL inductors — proven to raise power handling above the conventional IPD and to enable a thinner RF FEM — gives ASE and its customers a validated building block for the next generation of compact, high-power 5G radios.

Designing a 5G RF front-end module or filter that needs higher power handling in less space? Explore ASE's Fan-Out SiP capabilities at ase.aseglobal.com.

Frequently Asked Questions

Q: Why combine a foundry MIM capacitor with an OSAT Fan-Out RDL inductor? A: Each passive is built where it performs best. A foundry metal-insulator-metal (MIM) process delivers high-density, tight-tolerance capacitors, while the OSAT's Fan-Out redistribution layer (RDL) can be tuned for high-quality-factor inductors. Combining them into one filter structure pairs each component with the most suitable process — a heterogeneous integration approach that lifts overall filter performance.

Q: How much does this structure improve filter power handling? A: An 800 MHz low-pass filter (LPF) test vehicle built with the MIM-plus-Fan-Out-RDL structure sustains at least 38 dBm of input power, compared with about 36 dBm for a conventional integrated passive device (IPD). For the n77 and n79 band-pass filters, the maximum sustainable input power is 34 dBm for both.

Q: What insertion loss do the n77 and n79 filters achieve? A: The fabricated band-pass filters measured approximately 1.44 dB insertion loss for n77 and 2.07 dB for n79. Low pass-band insertion loss matters because any loss in the filter is transmit power the antenna never radiates, directly affecting the link budget.

Q: Why are n77, n78, and n79 important in 5G? A: They are three critical bands in the 5G FR1 sub-6GHz range, demanding because they operate at higher frequency and much wider bandwidth than legacy cellular bands. That combination stresses filter passives on quality factor, power handling, and parasitics, which is why the passive structure itself has to advance.

Q: How does Fan-Out RDL make the RF module thinner? A: Because the Fan-Out RDL can replace the conventional coreless packaging substrate, the filter passives are folded into the RDL stack instead of being mounted as discrete IPDs on a substrate. This removes a layer of module thickness and helps realize a thinner RF front-end module (FEM) — valuable where z-height and board area are scarce.
