Investigation of Low-Pressure Sn-Passivated Cu-to-Cu Direct Bonding in 3D-Integration
Copper-to-copper (Cu-to-Cu) direct bonding is the interconnect that makes true 3D integrated circuits (3D IC) possible — but the conventional process demands high temperature, high pressure, and copper surfaces planarized to near-perfect flatness, a combination that is hard and expensive to hold at scale. In a study published in Materials (2022), an ASE-affiliated team led by Po-Yu Kung takes a different route: passivate the electroplated copper with a thin layer of tin (Sn), and because Sn is soft and low-melting, achieve a successful bond at low temperature and just 1 MPa of pressure — with no planarization step at all. The result is a Cu-to-Cu bonding path that relaxes the three constraints most likely to limit 3D IC manufacturability.
Why Conventional Cu-to-Cu Bonding Is Hard to Scale
In a 3D IC, active chips are stacked and connected vertically to give the shortest possible interconnect and the smallest footprint. Cu-to-Cu direct bonding is central to that architecture because it forms a dense, low-resistance metal joint between stacked layers without solder. The problem is the conditions it normally requires.
Conventional Cu-to-Cu bonding asks for three things at once: high temperature, high pressure, and a high degree of height consistency across the bonding surfaces. The height-consistency requirement is the most punishing, because copper does not bond reliably unless the mating surfaces are planarized — typically by chemical-mechanical processes — to within a very tight tolerance. Any height difference between pads leaves gaps where the bond simply does not form. Combined with the thermal budget of a high-temperature step and the equipment demands of high pressure, these conditions raise cost and limit how widely the process can be applied across a stack of heterogeneous dies.
ASE's Approach: A Soft Sn Passivation Layer
The core idea is to put a thin, soft material between the copper surfaces that can flow enough to absorb height variation and form the joint under gentle conditions. The study passivates electroplated copper with tin (Sn). Because Sn is a soft metal with a low melting point, it deforms and bonds where rigid copper would not — enabling a successful bond at low temperature and low pressure (1 MPa) without any planarization process. Removing the planarization step is the headline simplification: the bond tolerates the as-plated height difference instead of requiring it to be polished away.
The team treated the process as an optimization problem across three variables — Sn thickness, bonding temperature, and bonding pressure — to find the conditions that produce a reliable joint.
| Variable | Values investigated | Purpose |
|---|---|---|
| Sn thickness | 1 μm, 800 nm, 600 nm | Find the minimum Sn needed to compensate the height difference |
| Bonding temperature | 220 °C and 250 °C | Identify the optimized thermal condition |
| Bonding pressure | Low pressure, down to 1 MPa | Confirm bonding under gentle force |
| Planarization | None required | Eliminate the costly flatness step |
Three Sn thicknesses — 1 μm, 800 nm, and 600 nm — were used specifically to calculate the minimum Sn thickness required to compensate for the height difference between copper surfaces, the parameter that decides whether the soft layer can bridge the as-plated topography. The bonding was conducted at 220 °C and 250 °C, and the optimized parameters with the required pressure were identified at each. The team also investigated the optimized parameters after copper planarization and observed that bonding succeeds even under severe conditions. Finally, transmission electron microscopy (TEM) was used to examine the adhesion between the different metals and the intermetallic compounds (IMCs) that form at the bonded interface — the microstructural evidence that the joint is sound.
What Low-Temperature, Low-Pressure Bonding Changes
For a 3D IC process engineer, each relaxed constraint removes a real barrier. Dropping to 1 MPa lowers the force the bonder must apply, which eases equipment requirements and reduces the risk of damaging fragile stacked dies. A lower bonding temperature shrinks the thermal budget, which matters when the stack already contains temperature-sensitive devices that a high-temperature step could degrade. And eliminating planarization removes an entire chemical-mechanical process step — with its cost, cycle time, and yield exposure — from the flow.
The minimum-Sn-thickness finding is what makes this practical rather than merely possible. By quantifying how much Sn is needed to compensate the height difference, the study gives a process engineer a design rule: specify enough Sn to absorb the expected as-plated topography, and the bond closes without polishing. That converts a brittle, tolerance-sensitive process into one with built-in margin — which is exactly what a manufacturable 3D IC interconnect needs. The TEM examination of the IMCs adds the reliability confidence, confirming the bond is a genuine metallurgical joint rather than a mechanical contact.
Where This Fits in ASE's 2.5D/3D IC and HI Roadmap
This bonding study sits at the process foundation of ASE's 2.5D and 3D IC packaging within the VIPack™ advanced packaging platform. ASE's 3D IC architecture stacks active chips for the shortest interconnect and smallest footprint, using through silicon via (TSV) and fine-pitch interconnect to reach ultra-high routing and I/O density — on the order of 0.4μm/0.4μm L/S and more than 400 microbumps/mm² in ASE's 2.5D/3D offerings. A robust, low-cost Cu-to-Cu bonding method is the kind of enabling process that lets those dense vertical stacks scale toward volume.
It is also a heterogeneous integration (HI) enabler. The whole premise of HI is combining separately manufactured dies — often with different process nodes and thermal tolerances — into one package. A bonding process that works at low temperature and low pressure is friendlier to exactly that mix of dies, because it does not subject a temperature- or force-sensitive partner die to a punishing bond step. Because ASE develops the bonding process, the TSV and stacking technology, and the failure-analysis and materials labs together, a method like this can be characterized against real 3D IC test vehicles and matured toward production.
What Comes Next
As 3D IC stacking deepens and the dies in a stack grow more heterogeneous, the bonding step has to get gentler, cheaper, and more tolerant of real-world surface variation — not the opposite. A Sn-passivated Cu-to-Cu process that bonds at 1 MPa and low temperature without planarization, with a quantified minimum Sn thickness and TEM-verified IMCs, points toward that future. It is the kind of process-level groundwork that turns the promise of dense 3D integration into something a fab can actually run.
Building a 3D IC stack that needs a manufacturable Cu-to-Cu interconnect? Explore ASE's 2.5D and 3D IC packaging capabilities at ase.aseglobal.com.
Frequently Asked Questions
Q: What is Cu-to-Cu direct bonding and why does 3D IC need it? A: Copper-to-copper (Cu-to-Cu) direct bonding forms a dense, low-resistance metal joint between stacked layers of a 3D integrated circuit (3D IC) without solder. It is central to 3D IC because vertical stacking gives the shortest interconnect and smallest footprint, and a direct copper joint provides the fine-pitch, high-density connection those stacks require.
Q: Why is conventional Cu-to-Cu bonding difficult? A: It requires high temperature, high pressure, and a high degree of height consistency across the bonding surfaces. The height-consistency demand usually means the copper must be planarized to a tight tolerance, because any height difference between pads leaves gaps where the bond does not form. Together these conditions raise cost and limit how widely the process can be applied.
Q: How does a tin (Sn) passivation layer help? A: Tin is a soft, low-melting metal. When electroplated copper is passivated with a thin Sn layer, the Sn deforms and bonds where rigid copper would not, enabling a successful bond at low temperature and just 1 MPa of pressure — and, critically, without any planarization step, because the soft Sn absorbs the as-plated height difference between surfaces.
Q: Why were three Sn thicknesses tested? A: The study used Sn thicknesses of 1 μm, 800 nm, and 600 nm specifically to calculate the minimum Sn thickness required to compensate for the height difference between the copper surfaces. That minimum is the key design rule: enough Sn to bridge the expected as-plated topography lets the bond close without polishing.
Q: How was the bond quality verified? A: Bonding was conducted at 220 °C and 250 °C, with optimized parameters identified at each temperature, and the process was shown to succeed even after copper planarization under severe conditions. Transmission electron microscopy (TEM) was then used to examine the adhesion between metals and the intermetallic compounds (IMCs) at the interface, confirming a genuine metallurgical joint.
