Antenna in Package with Double-Layer Parasitic Elements for 28/39 GHz Applications
A single 5G millimeter-wave (mmWave) handset has to talk across two widely separated frequency bands — roughly 28 GHz and 39 GHz — and it has to do so from inside a package thin enough to disappear into a phone. In a 2023 IEEE AP-S/USNC-URSI paper, an ASE team led by Ming-Lung Kung shows how to cover both bands in dual polarization from one antenna-in-package (AiP) just 0.92 mm thick, using double-layer parasitic elements to stretch a stacked-patch antenna across a low band of 24.2–29.6 GHz and a high band of 36.6–40.5 GHz. The result matters because bandwidth, polarization diversity, and z-height are usually traded against one another — and this design holds all three at once.
Why mmWave Bandwidth Is Hard to Win in a Thin Package
mmWave is attractive for the same reason it is difficult: the short wavelengths between 28 and 100 GHz open up wide bandwidths and high data capacity, but they also force the antenna and the radio to sit within microns of each other or lose the signal to interconnect loss. That is the entire premise of AiP — integrate the antenna array directly into the IC package so the transceiver sits as close to the radiating elements as possible, mitigating the attenuation that kills link budgets at these frequencies.
The catch is that a patch antenna is naturally narrowband. A single resonant patch covers only a slice of spectrum, while 5G mmWave deployment spans the 3GPP n257/n258/n261 cluster near 28 GHz and the n260 band near 39 GHz. Widening a patch usually means making the package thicker — more dielectric height buys more bandwidth — but added z-height is exactly what a phone, a CPE, or a fixed-wireless module cannot afford. The engineering question this paper answers is how to broaden the band without paying for it in thickness.
ASE's Approach: Stacked Patches Plus Double-Layer Parasitic Elements
The design starts from a stacked patch antenna — a driven patch with a second resonant patch above it — and then adds double-layer parasitic elements, the core innovation of the paper. Parasitic elements are unfed conductors placed near the driven patch; they resonate at slightly offset frequencies and merge with the main resonance to widen the usable band. By arranging these parasitic elements across two layers rather than one, ASE introduces additional resonances that broaden both the 28 GHz and 39 GHz responses, turning a pair of narrow patches into a genuinely dual-band, dual-polarization radiator.
All of this is built into an 8-layer package only 0.92 mm thick, with the antenna formed on a multilayer organic substrate of the kind ASE already uses for FCBGA-based AiP. The structure is summarized below.
| Parameter | Value |
|---|---|
| Antenna type | Stacked patch with double-layer parasitic elements |
| Package construction | 8-layer multilayer organic substrate |
| Package thickness | 0.92 mm |
| Polarization | Dual polarization |
| Operation | Dual band |
| Low band | 24.2 – 29.6 GHz |
| High band | 36.6 – 40.5 GHz |
Dual polarization is not a cosmetic feature here. Two orthogonal polarizations let a beamforming front end carry independent data streams or improve link robustness through polarization diversity — the foundation of the MIMO schemes ASE applies in its highly integrated mmWave modules. Delivering it from the same thin stack as the bandwidth enhancement is what makes the design practical rather than merely clever.
What the Bands Actually Cover
The measured passbands map cleanly onto real 5G allocations, which is the test of whether an antenna design is deployable. The 24.2–29.6 GHz low band spans the heart of the 28 GHz cluster — 3GPP n258 (24.25–27.5 GHz), n261 (27.5–28.35 GHz), and the lower edge of n257 (26.5–29.5 GHz) — while the 36.6–40.5 GHz high band covers n260 (37–40 GHz). A 5.4 GHz-wide low band and a 3.9 GHz-wide high band give the front-end designer margin for process variation, detuning from nearby metal, and the temperature drift that any handset endures. For an OEM, one AiP that addresses both the 28 GHz and 39 GHz deployments removes a second antenna design from the bill of materials and the integration schedule.
Where This Fits in ASE's AiP Portfolio
This paper is one step in a sustained ASE program on mmWave AiP rather than a one-off. The same RF group has published a broadband dual-polarized 2×2 array for beamforming, a dual-band 28/39 GHz AiP using H-type slot structures for band isolation, and a compact array using a frequency-selective surface — a body of work that consistently attacks the same problem of fitting wide-band, multi-band, polarization-diverse antennas into manufacturable organic-substrate packages. The double-layer parasitic technique reported here is the bandwidth-and-thinness contribution to that line.
Commercially, this lands inside ASE's AiP and System-in-Package (SiP) offering, where the antenna array integrates with the RF transceiver, power management IC, passives, and EMI shielding through double-side molding and selective molding. Because ASE qualifies these structures on the same multilayer organic substrates and FCBGA-based AiP flows it runs in volume — backed by an AiP measurement system developed with Keysight for over-the-air validation — a design proven in a conference paper has a defined path to a shippable module rather than a research result that stalls at the test bench.
What Comes Next
As 5G mmWave broadens and 6G research pushes toward even higher frequencies, the pressure to cover more spectrum from thinner, polarization-diverse packages only intensifies. Double-layer parasitic elements give ASE a repeatable lever for widening patch-antenna bandwidth without adding z-height, and the dual-band, dual-polarization result shown here is directly reusable as designs move toward carrier aggregation across the 28 and 39 GHz bands. Paired with ASE's heterogeneous integration (HI) and SiP capabilities, the technique is a building block for the compact, multi-band front ends that next-generation wireless will demand.
Designing a multi-band 5G mmWave front end? Explore ASE's Antenna-in-Package and System-in-Package solutions at ase.aseglobal.com.
Frequently Asked Questions
Q: What is an antenna-in-package (AiP)? A: An antenna-in-package (AiP) integrates the antenna array directly into the IC package that carries the RF transceiver. Placing the antenna within microns of the radio mitigates the interconnect loss that becomes severe at millimeter-wave (mmWave) frequencies, while shrinking the overall module footprint — which is why AiP has become the mainstream approach for 5G mmWave.
Q: What do double-layer parasitic elements do for a patch antenna? A: Parasitic elements are unfed conductors placed near the driven patch that resonate at slightly offset frequencies and merge with the main resonance to widen the usable bandwidth. Arranging them across two layers introduces additional resonances, broadening both the 28 GHz and 39 GHz responses without increasing package thickness.
Q: Which frequency bands does this AiP cover? A: It operates in two bands — a low band from 24.2 to 29.6 GHz and a high band from 36.6 to 40.5 GHz — covering the 3GPP 28 GHz cluster (n257/n258/n261) and the 39 GHz n260 band in dual polarization.
Q: Why does dual polarization matter in 5G mmWave? A: Two orthogonal polarizations let a beamforming front end carry independent data streams or improve link robustness through polarization diversity, which is the basis of MIMO. Supporting it from one thin AiP lets a single module serve advanced 5G beamforming schemes.
Q: How thin is the package, and why does thickness matter? A: The antenna is built into an 8-layer multilayer organic substrate just 0.92 mm thick. Z-height is a hard constraint in handsets, CPE, and fixed-wireless modules, so achieving wide, dual-band coverage at sub-millimeter thickness is what makes the design deployable in real products.
