Design of Dual-Band (28/39GHz) Antenna-in-Package with broad bandwidth for 5G Millimeter-Wave Application
Put a 28 GHz radiator and a 39 GHz radiator inside the same 13 × 13 mm antenna-in-package (AiP) and they will fight each other — the two bands couple, interference rises, and isolation collapses. In a 2022 EPTC paper, an ASE team led by Sheng-Chi Hsieh shows how to stop that fight with an H-type slot antenna structure that holds better than 15 dB of isolation between the low and high bands, while multi-parasitic elements deliver roughly 5 GHz of bandwidth at 28 GHz and 6 GHz at 39 GHz, with gains above ~11.5 dBi and 10 dBi respectively. The result is a single compact AiP that serves both 5G mmWave bands without the two interfering.
Why Dual-Band mmWave Packaging Is Harder Than Single-Band
5G mmWave is not one band but several, split across two clusters: the 28 GHz group (3GPP n257/n258/n261) and the 39 GHz band. A device that wants both has two options — build two separate antenna modules, or integrate both bands into one. The integrated route saves board area, cost, and a second design effort, but it introduces a problem single-band designs never face: two radiating structures at very different frequencies, packed into the same few square millimeters, couple to each other. That coupling raises inter-band interference and degrades isolation, and poor isolation means energy meant for the 28 GHz path bleeds into the 39 GHz path and vice versa, corrupting both.
So a dual-band AiP has to solve two problems at once. Each band must still be broadband — narrowband patches cannot cover the full 28 or 39 GHz allocations — and the two bands must stay electrically separated despite sharing a tiny package. Solve only the first and you get wide bands that interfere; solve only the second and you get clean but narrow bands. This design addresses both.
ASE's Approach: H-Type Slot Structure Plus Multi-Parasitic Elements
The antenna is a stacking patch structure with multi-parasitic elements built on a 10-layer (4+2+4) multilayer organic substrate, arranged as a 2×2 array in a package about 13 × 13 mm². Two design moves carry the dual-band requirement.
| Design feature | Purpose |
|---|---|
| Stacking patch + multi-parasitic elements | Broaden bandwidth in each band |
| H-type slot antenna structure | Improve interference and isolation between the 28 and 39 GHz bands |
| 10-layer (4+2+4) organic substrate | Cost-effective, manufacturable platform for both bands |
| 2×2 array, dual feeding | Gain and beam steering with polarization support |
The multi-parasitic elements do the bandwidth work — adding resonances around each driven patch so the response stretches across the full width of each allocation rather than a narrow slice. The H-type slot antenna structure is the part that makes dual-band integration viable: by shaping the slot geometry, ASE improves the interference behavior and raises isolation between the low and high bands, keeping the two paths electrically distinct inside the shared package. It is the targeted fix for the exact problem that makes dual-band harder than single-band.
Measured Performance Across Both Bands
The design is validated band by band, and the numbers show broad coverage with the inter-band separation intact.
| Band | Bandwidth | Gain | Notes |
|---|---|---|---|
| Low band (28 GHz) | > 10 dB return loss across 24.6 – 29.65 GHz (~5 GHz) | above ~11.5 dBi | High-gain radiation pattern for 28 GHz applications |
| High band (39 GHz) | ~6 GHz across 38 – 44 GHz | 10 dBi | — |
| Inter-band isolation | — | — | > 15 dB between low and high band |
| Beam steering | 27 GHz, four quadrants | peak 11.1 dBi | θ=28°, Φ=312° (quadrant IV) |
The ~5 GHz low-band width (24.6–29.65 GHz) covers the whole 28 GHz cluster — 3GPP n257, n258, and n261 — while the 6 GHz high-band width (38–44 GHz) gives generous margin around the 39 GHz allocation. Gains above ~11.5 dBi at 28 GHz and 10 dBi at 39 GHz mean each band carries a usable link, not a marginal one. The number that proves the architecture, though, is the >15 dB inter-band isolation: it is the evidence that the H-type slot structure actually keeps the two bands apart, which is what allows them to share one module in the first place. Finally, the 3D beam-steering simulation at 27 GHz reaching 11.1 dBi in quadrant IV confirms the array steers by controlling per-element phase, so the dual-band module is also a beamforming module. For an OEM, one part that covers 28 and 39 GHz, steers, and keeps the bands clean replaces two antenna designs and the integration work between them.
Where This Fits in ASE's AiP Portfolio
This dual-band design is one thread in a sustained ASE program on mmWave AiP. The same RF group has reported a broadband single-band 2×2 array for beamforming, a double-layer-parasitic AiP that reaches 28 and 39 GHz from a 0.92 mm stack, and a test-socket methodology for fast array validation — a body of work that repeatedly targets wide-band, multi-band, beam-steerable antennas on manufacturable organic substrates. The H-type slot contribution here is the inter-band isolation technique that makes putting both bands in one package practical.
Commercially, this lives inside ASE's AiP and System-in-Package (SiP) offering, where the antenna array integrates with the RF transceiver, power management, passives, and EMI shielding, and is qualified using ASE's mmWave measurement capability — including the Keysight-developed compact antenna test range for over-the-air validation. Because ASE runs these multilayer organic substrates in volume, a dual-band design proven at a conference has a defined route to a shippable module.
What Comes Next
As 5G mmWave deployment broadens and devices increasingly need both the 28 and 39 GHz bands, dual-band AiP moves from a nice-to-have to a default requirement, and the isolation problem this paper solves becomes central rather than incidental. The H-type slot structure and multi-parasitic bandwidth approach proven here carry forward toward carrier aggregation across both bands and, eventually, the even higher frequencies of 6G. Combined with ASE's heterogeneous integration (HI) and SiP capabilities, the dual-band AiP is a building block for the compact, multi-band front ends that next-generation wireless demands.
Designing a dual-band 5G mmWave module? Explore ASE's Antenna-in-Package and System-in-Package solutions at ase.aseglobal.com.
Frequently Asked Questions
Q: What makes a dual-band mmWave AiP harder to design than a single-band one? A: Two radiating structures at very different frequencies — 28 GHz and 39 GHz — packed into the same small package couple to each other, raising inter-band interference and degrading isolation. A dual-band AiP must keep each band broadband and keep the two bands electrically separated at the same time, which a single-band design never has to do.
Q: How does the H-type slot structure help? A: By shaping the slot geometry, the H-type slot antenna structure improves interference behavior and raises isolation between the low and high bands to better than 15 dB. That separation is what lets the 28 and 39 GHz paths share one compact package without corrupting each other.
Q: What bandwidth and gain does the design achieve? A: The 28 GHz low band has more than 10 dB return loss across 24.6–29.65 GHz (about 5 GHz of bandwidth) with gain above roughly 11.5 dBi, and the 39 GHz high band offers about 6 GHz of bandwidth across 38–44 GHz with 10 dBi gain. Isolation between the two bands is better than 15 dB.
Q: Which 5G bands does it cover? A: The low band spans the full 28 GHz mmWave cluster defined by 3GPP — n257, n258, and n261 — and the high band covers the 39 GHz allocation. A 3D beam-steering simulation at 27 GHz reaches a peak realized gain of 11.1 dBi in quadrant IV.
Q: How big is the module? A: The dual-band AiP is about 13 × 13 mm², built as a 2×2 array on a 10-layer (4+2+4) multilayer organic substrate — a compact, cost-effective platform that integrates both bands rather than requiring two separate antenna modules.
