Dk/Df Extraction and Moisture Effect on mmWave Fan-out Package Design

At 28 GHz and above, the dielectric properties of the package material stop being a second-order detail and become the design. A polyimide (PI) film that absorbs a fraction of a percent of moisture shifts its dielectric constant (Dk) and dissipation factor (Df) enough to change a mmWave transmission line's insertion loss and phase — and a phase error in a beamforming antenna array is a pointing error. In a 2022 IMPACT paper, an ASE team led by Chiung-Ying Kuo confronts this directly: first establish a reliable method to extract Dk and Df of the fan-out PI dielectric, then quantify how moisture uptake degrades transmission line loss and phase across the mmWave band. The goal is a package model an RF designer can trust before committing silicon.

Why Dielectric Characterization Decides mmWave Fan-out Performance

Fan-out packaging builds a redistribution layer (RDL) directly on a reconstituted wafer, embedding the die in mold compound and routing signals through PI-based dielectric layers rather than a laminate substrate. That architecture is what lets ASE integrate a 5G mmWave RF transceiver and its antenna array in one compact module — but it also puts the PI dielectric squarely in the signal path of every high-frequency trace.

At sub-6GHz, modest variation in dielectric properties is tolerable. At mmWave frequencies, it is not. Dielectric loss scales with frequency, so the Df of the PI film directly sets how much signal a transmission line dissipates per millimeter, and Dk sets the line's effective wavelength and therefore its phase delay. If the material's Dk and Df are not characterized accurately up into the mmWave range, the electromagnetic model used to design the antenna feed and matching network is wrong from the start — and the error compounds across a multi-element array.

PI introduces a second complication: it is hygroscopic. The paper notes that the moisture effect of PI is pronounced in both stress and electrical performance, meaning absorbed water measurably alters the very Dk and Df the designer is trying to pin down. Characterizing the dry material is not enough; the design has to account for how those properties move as the package takes on moisture in real operating and reliability conditions.

ASE's Approach: Extract Dk/Df First, Then Quantify the Moisture Shift

The paper addresses the problem in two stages. First, it introduces a method to extract the dielectric constant (Dk) and dissipation factor (Df) of the fan-out PI dielectric across frequency up into the mmWave band. Establishing this extraction method is the foundation — without trustworthy material parameters, no downstream transmission line or antenna simulation is meaningful.

Second, with the extraction method in hand, the study characterizes the moisture effect on transmission line loss and phase, again carried up to mmWave frequencies. This is the move that turns a material measurement into a design tool: it tells the engineer not just what the PI's Dk and Df are when dry, but how far insertion loss and phase drift once the dielectric has absorbed moisture.

Study element	What ASE characterized	Why it matters at mmWave
Dk/Df extraction method	Dielectric constant and dissipation factor of fan-out PI, vs. frequency	Anchors the EM model used for antenna and feedline design
Moisture effect on loss	Change in transmission line insertion loss after moisture uptake	Predicts real-world link budget margin, not just dry-state
Moisture effect on phase	Change in transmission line phase after moisture uptake	Protects beamforming accuracy in mmWave antenna arrays
Frequency range	Up to mmWave (e.g., 28/39 GHz class)	Where dielectric loss and phase sensitivity dominate

Specific extracted Dk/Df values and the measured percentage shift in loss and phase versus moisture level are reported in the original IMPACT paper [TBD - 待確認]; ASE's knowledge base does not restate these figures, and they are not reproduced here to avoid fabricating data.

What the Moisture Model Changes for the Designer

Quantifying the moisture-driven drift in Dk and Df converts a hidden risk into a budgeted one. An RF engineer designing a mmWave antenna-in-package can now feed a moisture-adjusted dielectric model into the electromagnetic simulation rather than a single dry-state value, sizing the feedline and matching network with margin for the worst-case absorbed-moisture condition. That is the difference between a module that passes characterization on a dry day and one that holds its insertion loss and phase across humidity, reflow, and reliability stressing.

For a beamforming array, phase stability is the payoff that matters most. Each antenna element's phase has to track the design target for the array to steer accurately; a moisture-induced phase shift that varies element to element smears the beam. By characterizing the phase sensitivity to moisture up front, the design can compensate — or the material and stackup can be selected to keep the drift within the array's phase-error budget. The same model also informs whether a low-Dk/low-Df antenna FPC or hybrid substrate is needed, a choice ASE already offers in its mmWave antenna-in-package (AiP) portfolio specifically to minimize high-frequency signal loss.

Where This Fits in ASE's Fan-out and AiP Capability

This work sits inside ASE's broader fan-out and SiP-based mmWave packaging capability. ASE's Fan-Out System-in-Package (FOSiP) and antenna-in-package (AiP) solutions integrate the RF transceiver, antenna array, and passive components into a single module using exactly the PI-based RDL stackups this paper characterizes. Within the VIPack™ advanced packaging platform, fan-out RDL is the building block that makes that integration possible — and dielectric characterization is what makes it predictable. Material-level rigor of this kind is the unglamorous foundation under every high-frequency package ASE qualifies.

Because ASE develops the fan-out process, the dielectric materials database, and the mmWave measurement capability under one roof — including an in-house S-parameter and over-the-air measurement suite — a Dk/Df extraction method can be validated against real production stackups and fed straight back into customer design kits, shortening the path from material selection to a qualified mmWave module.

What Comes Next

As 5G mmWave deployment broadens and 6G research pushes toward even higher frequencies, the sensitivity of package performance to dielectric properties only grows. A validated Dk/Df extraction method, paired with a quantified moisture model, gives ASE and its customers a repeatable way to design fan-out mmWave packages that meet their loss and phase targets in the real world rather than only on the test bench. It is the kind of material-physics groundwork that makes the next generation of antenna-in-package modules manufacturable at scale.

Designing a mmWave fan-out or antenna-in-package module? Explore ASE's Fan-Out SiP and AiP capabilities at ase.aseglobal.com.

Frequently Asked Questions

Q: What are Dk and Df, and why do they matter in mmWave packaging? A: Dk (dielectric constant) sets a transmission line's effective wavelength and therefore its phase delay, while Df (dissipation factor) sets how much signal the dielectric dissipates as loss. At mmWave frequencies (28 GHz and above), dielectric loss scales with frequency, so accurate Dk/Df values for the package's polyimide (PI) dielectric are essential — an inaccurate material model produces a wrong antenna and feedline design from the start.

Q: Why does moisture affect fan-out package performance? A: Polyimide (PI), the common dielectric in fan-out packages, is hygroscopic — it absorbs moisture from the environment. Absorbed water changes the PI's Dk and Df, which in turn shifts the transmission line's insertion loss and phase. Because this drift is pronounced at mmWave, the design has to account for the moisture-adjusted dielectric properties, not just the dry-state values.

Q: How does ASE extract the Dk and Df of a fan-out dielectric? A: The paper introduces a method to extract the dielectric constant and dissipation factor of the fan-out PI material across frequency up into the mmWave range, then uses those parameters to characterize how transmission line loss and phase change with moisture uptake. This gives RF designers a trustworthy, frequency-dependent material model for electromagnetic simulation.

Q: How does moisture-induced phase shift affect a beamforming antenna? A: In a beamforming array, each element's phase must track its design target for the array to steer the beam accurately. A moisture-induced phase shift that varies from element to element smears the beam and degrades pointing accuracy. Characterizing phase sensitivity to moisture up front lets the design compensate or select materials that keep the drift within the array's phase-error budget.

Q: What is fan-out packaging and why is it used for mmWave? A: Fan-out packaging builds a redistribution layer (RDL) directly on a reconstituted wafer with the die embedded in mold compound, eliminating a separate laminate substrate. It enables short interconnects, low profile, and tight integration of an RF transceiver with its antenna array — making it well suited to compact 5G mmWave antenna-in-package (AiP) and System-in-Package modules.
