Broadband Dual-Polarized Antenna Array using AiP Techniques for 5G mmWave Beamforming Systems
A 5G mmWave beamformer is only as good as the antenna array feeding it — and that array has to deliver high gain across the full 28 GHz band, in two polarizations, while steering a beam through 3D space, all on a substrate cheap enough to ship in volume. In a 2022 IMPACT paper, an ASE team led by Wen-Chun Hsiao reports a 2×2 dual-polarized antenna-in-package (AiP) array that does exactly this: a realized gain of 10.7 to 12.4 dBi across 24.65–29.65 GHz, port-to-port isolation better than 18 dB, and a steered beam reaching 11.1 dBi — built on a 4+2+4 cost-effective multilayer organic substrate measuring just 13 × 13 × 0.87 mm³.
The Beamforming Array Problem at 28 GHz
mmWave beamforming exists to solve a physics problem: at 28 GHz, free-space path loss is severe, so the only way to close a link is to concentrate energy into a steerable beam using a phased array. But that shifts the burden onto the antenna. The array must hold high gain across the entire operating band, support two polarizations so the system can run MIMO or polarization diversity, keep the elements electrically isolated so adjacent beams do not corrupt one another, and steer cleanly as the phase of each element is adjusted.
A single patch antenna fails most of these requirements at once — it is narrowband, single-polarized, and on its own provides too little gain to steer usefully. The design challenge is to fix all of these without resorting to exotic, expensive substrates, because a 5G antenna that only works on a premium material never reaches a phone or a customer-premises device. ASE's answer keeps the antenna on a standard cost-effective organic substrate and engineers the bandwidth and polarization into the antenna geometry itself.
ASE's Approach: Stacked Patches, Parasitic Elements, and Dual Feeds
Each antenna element combines three ingredients: one driven patch, one stacked patch above it, and four parasitic elements around it. The driven and stacked patches form a two-resonance structure whose bandwidth depends on the stacking ratio between them — a parameter the ASE team simulated and optimized directly. The four parasitic elements then add further resonances that expand the band, so the element achieves broadband behavior without the dielectric thickness a single patch would need.
| Parameter | Value |
|---|---|
| Array configuration | 2×2 dual-polarized |
| Substrate | 4+2+4 multilayer organic, cost-effective |
| Module size | 13 × 13 × 0.87 mm³ |
| Element structure | 1 driven patch + 1 stacked patch + 4 parasitic elements |
| Polarization mechanism | Dual feeding ports per element |
| Beam-steering frequency | 27 GHz, four quadrants |
| 3GPP coverage | n257, n258, n261 (28 GHz bands) |
Dual polarization comes from giving each element two feeding ports, so the same physical patch radiates in both vertical and horizontal polarization depending on which port drives it. Arraying four such elements in a 2×2 grid produces the aperture needed for both gain and steering. This is the architecture that lets a single compact module serve a full 5G mmWave beamforming front end rather than a single fixed link.
Measured Performance: Gain, Isolation, and Beam Steering
The design holds up where it matters — in the simulated and measured electrical results, which the paper reports in detail.
| Metric | Result |
|---|---|
| Single-element return loss (>10 dB) | 24.60 – 29.65 GHz |
| Single-element realized gain | > 5.5 dBi |
| Array realized gain (V-pol and H-pol) | 10.7 – 12.4 dBi across 24.65 – 29.65 GHz |
| Port-to-port isolation | > 18 dB in band |
| Cross-polarization isolation | > 14 dB in band |
| Peak steered gain | 11.1 dBi at θ=28°, Φ=312° (quadrant IV, 27 GHz) |
The array's 10.7–12.4 dBi realized gain across a ~5 GHz span, in both polarizations, is the headline: it means the beamformer keeps usable signal strength across the entire 28 GHz allocation regardless of polarization, rather than peaking at one frequency and falling away. The >18 dB port-to-port isolation and >14 dB cross-polarization isolation matter just as much — without them, the two polarization channels leak into each other and the MIMO benefit collapses. Finally, simulating 3D beam steering across all four quadrants and reaching 11.1 dBi in quadrant IV confirms the array does what a beamforming antenna must do: redirect its peak by controlling the phase at each element. For a system designer, those three results together — flat broadband gain, clean isolation, and verified steering — are the difference between an antenna that demos and one that can anchor a product.
Why the Cost-Effective Substrate Is the Real Headline
The most strategically important number in the paper is the cheapest one: a 4+2+4 multilayer organic substrate, 0.87 mm thick. Achieving 12.4 dBi array gain and clean dual-polarized steering on standard organic build-up — rather than a low-loss exotic laminate — is what makes the design manufacturable at the scale 5G demands. This is the through-line of ASE's mmWave AiP work: the company's leadership in System-in-Package (SiP) and heterogeneous integration (HI) lets it integrate the RF transceiver, power management, passives, and EMI shielding around an antenna array like this one, and qualify the whole module on substrates it already runs in volume. The same RF group has since extended the approach to dual-band 28/39 GHz designs and to test-socket measurement methods for fast array validation — but this broadband single-band array is the foundation the later work builds on.
What Comes Next
Broadband, dual-polarized, steerable, and cheap to build is the combination 5G mmWave deployment actually needs, and this 2×2 array demonstrates all four at once on a production-grade substrate. As beamforming front ends scale to larger arrays and push toward dual-band operation and eventually 6G frequencies, the design levers proven here — stacking-ratio optimization, parasitic-element bandwidth expansion, and dual-feed polarization — carry directly forward. Combined with ASE's AiP measurement system developed with Keysight for over-the-air validation, the array represents a repeatable path from antenna concept to qualified mmWave module.
Building a 5G mmWave beamforming module? Explore ASE's Antenna-in-Package and System-in-Package solutions at ase.aseglobal.com.
Frequently Asked Questions
Q: Why does 5G mmWave need a beamforming antenna array? A: At 28 GHz, free-space path loss is severe, so a single antenna cannot close a usable link. A phased array concentrates energy into a steerable beam, which is why mmWave systems rely on beamforming arrays rather than individual antennas — and the array must deliver high gain across the band while steering cleanly.
Q: How does this AiP array achieve broadband performance on a cheap substrate? A: Each element pairs a driven patch with a stacked patch — whose bandwidth depends on the stacking ratio — and adds four parasitic elements that introduce further resonances. This widens the band through antenna geometry rather than exotic materials, so the array works on a standard 4+2+4 multilayer organic substrate.
Q: What gain and isolation does the array achieve? A: Across 24.65–29.65 GHz the 2×2 array delivers a realized gain of 10.7 to 12.4 dBi in both vertical and horizontal polarization, with port-to-port isolation better than 18 dB and cross-polarization isolation better than 14 dB. A single element reaches over 5.5 dBi with return loss above 10 dB from 24.60 to 29.65 GHz.
Q: How is dual polarization implemented? A: Each antenna element has two feeding ports, so the same physical patch radiates in vertical or horizontal polarization depending on which port is driven. This dual-feed approach lets the array support MIMO and polarization diversity from one compact structure.
Q: Which 5G bands does the array cover? A: The broadband design covers all the 28 GHz mmWave bands defined in the 3GPP standard — n257, n258, and n261 — and a 3D beam-steering simulation at 27 GHz reaches a peak realized gain of 11.1 dBi in quadrant IV.
