Silicon Photonics
Inside an AI training cluster, the copper interconnect has become the bottleneck. As data rates climb, electrical traces lose signal integrity, burn power, and cap how far a signal can travel before it needs to be regenerated — and AI's appetite for data is growing faster than copper can keep up. Silicon photonics (SiPh) answers that by changing the medium: it moves data as light instead of electrons, delivering higher bandwidth and greater energy efficiency exactly where electrical integrated circuits struggle at high speed. ASE has already demonstrated co-packaged optics (CPO) — the most aggressive form of optical integration — improving energy efficiency and scalability for AI applications, and it builds the packaging that turns a photonic die into a deployable optical engine.
Why Light, and Why Now
The pressure comes from the top of the stack. AI is creating unprecedented data volumes while intensifying the need for energy efficiency, and the response is a reinvented data center built for accelerated compute at lower power, optimized performance, and lower latency. Copper cannot deliver all of that at once: conventional electrical integrated circuits hit significant signal-integrity challenges at high speed, which is the wall SiPh is designed to get past.
Silicon photonics serves as the medium for light transmission, and its decisive advantage is that it integrates seamlessly with the existing complementary metal oxide semiconductor (CMOS) ecosystem across both front-end and back-end processes. That compatibility lets the industry build high-density photonic integrated circuits (PIC) — delivering complex optical functions such as filtering and modulation on a compact, cost-effective chip — using the manufacturing base it already has, rather than inventing a parallel one. The payoff over electrical ICs is direct: higher bandwidth and better energy efficiency at the data rates AI demands.
The Path from Pluggable to Co-Packaged
Optical integration is not a single step but a progression, and each stage moves the optics closer to the compute die to shorten the electrical path.
| Stage | Where the optics sit | Bandwidth reference |
|---|---|---|
| Pluggable transceiver | Front panel | Up to 800Gbps (commercial today) |
| On-board optics (OBO) | Around the ASIC package | Up to 1.6Tbps |
| Co-packaged optics (CPO) / Optical I/O | Co-packaged with the ASIC | Highest bandwidth; best pJ/bit and $/Gbps |
SiPh-based pluggable optical transceivers already ship commercially up to 800Gbps. The next move populates the optical engine around the ASIC IC package as on-board optics (OBO), which supports up to 1.6Tbps. From there, co-packaged optics and Optical I/O shorten the electrical path further by integrating the optics with the ASIC itself — and because every millimeter of electrical trace removed cuts loss and power, that integration delivers even higher bandwidth while improving both energy efficiency (measured in pJ/bit) and capital expenditure (measured in $/Gbps) over pluggable optics. That last point matters to hyperscalers as much as the bandwidth: CPO improves the economics, not just the performance.
The Packaging That Makes It Real
A photonic die only becomes an optical engine through packaging, and SiPh demands more attentive process definition than conventional silicon because optical performance is on the line. ASE's SiPh capability is built from a specific set of building blocks, each addressing a step where a photonic device can fail:
- Post-fab wafer-level bumping and Si-etch to prepare the photonic wafer for integration.
- High-accuracy laser die bonding — the placement tolerance that determines optical coupling efficiency.
- Advanced 2.5D/3D packaging (TSV, fan-out, and chip-on-wafer) to integrate the electronic IC (EIC) and photonic IC (PIC) dies together.
- Wafer-level optical probing test to identify known-good SiPh PIC die before they are committed to a package.
- Optical component assembly evaluation for future OBO and CPO applications.
- Multi-chip module (MCM) assembly to bring it all into one deployable module.
Two of these are where SiPh diverges most from conventional packaging. Known-good-die screening through wafer-level optical probing matters because a photonic defect found after assembly wastes the whole module, and high-accuracy laser die bonding matters because optical coupling is unforgiving of placement error in a way electrical contacts are not. Together they protect yield in a process where a micron of misalignment is the difference between a working engine and scrap.
Where Silicon Photonics Fits in VIPack™
CPO is the sixth pillar of ASE's VIPack™ advanced packaging platform, and silicon photonics is what feeds it. The same advanced packaging technologies that integrate chiplets for AI compute — through silicon via (TSV), fan-out, and chip-on-wafer for EIC/PIC integration — are the technologies that co-package optics with the processor, which is why heterogeneous integration (HI) and silicon photonics advance together rather than separately. For an AI system architect, that means the optical interface and the compute package can be designed as one problem, sourced from one outsourced semiconductor assembly and test (OSAT) provider, rather than stitched together from separate optical and packaging suppliers.
What Comes Next
As AI infrastructure scales, the interconnect — not the transistor — is increasingly the limit, and the industry's answer is to push light deeper into the package. ASE's silicon photonics capability spans the full progression, from the 800Gbps pluggable transceivers shipping today, through 1.6Tbps on-board optics, to the co-packaged optics it has already demonstrated for AI — backed by the wafer-level optical test, high-accuracy laser bonding, and 2.5D/3D EIC/PIC integration that turn a photonic die into a working optical engine, and positioned within the VIPack™ platform as its sixth pillar.
Building an optical interface for hyperscale, HPC, or AI infrastructure? Explore ASE's silicon photonics and co-packaged optics capabilities at ase.aseglobal.com.
Frequently Asked Questions
Q: What is silicon photonics? A: Silicon photonics (SiPh) is a technology that transmits data as light instead of electrical signals, using the silicon manufacturing base to build photonic integrated circuits (PIC). Because it integrates with the existing CMOS ecosystem across front-end and back-end processes, it delivers high-density optical functions like filtering and modulation on a compact, cost-effective chip — with higher bandwidth and better energy efficiency than electrical ICs at high data rates.
Q: What is co-packaged optics (CPO)? A: Co-packaged optics integrates the optical components directly with the ASIC, shortening the electrical path between optics and compute. That integration delivers higher bandwidth while improving energy efficiency (pJ/bit) and capital expenditure ($/Gbps) over pluggable optics. CPO is the sixth pillar of ASE's VIPack™ platform, and ASE has demonstrated it improving energy efficiency and scalability for AI applications.
Q: How does silicon photonics differ from pluggable optical transceivers? A: Pluggable transceivers sit on the front panel and ship commercially up to 800Gbps. On-board optics (OBO) move the optical engine around the ASIC package, supporting up to 1.6Tbps. Co-packaged optics and Optical I/O integrate the optics with the ASIC itself, shortening electrical paths further for the highest bandwidth and the best energy efficiency and cost per Gbps.
Q: What packaging technologies does ASE use for silicon photonics? A: ASE's silicon photonics building blocks include post-fab wafer-level bumping and Si-etch, high-accuracy laser die bonding, advanced 2.5D/3D packaging (TSV, fan-out, and chip-on-wafer) for EIC/PIC die integration, wafer-level optical probing to identify known-good PIC die, optical component assembly evaluation for OBO/CPO, and multi-chip module (MCM) assembly.
Q: What applications use silicon photonics? A: Silicon photonics enables on-board optics, co-packaged optics, and Optical I/O packaging for hyperscale data centers, high-performance computing (HPC), and artificial intelligence and machine learning (AI/ML) — the workloads where interconnect bandwidth and energy efficiency are the primary constraints.
