Unlocking More in Wearable Devices
A modern smartwatch or earbud has to hold a processor, memory, connectivity radios, sensors, and power management inside a volume measured in millimeters — and customers keep asking for more functions in the same or smaller footprint. The binding constraint is no longer transistor performance; it is real estate on the board. System-in-package (SiP) answers that constraint directly: ASE integrates more than 30 components onto a single package as small as 4mm × 8mm or 4.55mm × 9mm, cutting product size and shaving overall weight by 1 gram or more. That density is why SiP has become the preferred packaging route for the next generation of wearables.
Why SiP Became the Default for Wearables
SiP is a packaging technique that integrates different sensors and chips with multiple functions — microcontroller unit (MCU), memory, and more — within a single small form factor. Rather than spreading those parts across a printed circuit board, SiP consolidates them into one module, which is what enables the dramatic size reduction wearables demand.
The benefits compound beyond size. Dense circuitry lowers power consumption, improves radio frequency (RF) performance, and maximizes functional capacity in the available space. Additional IC testing — including testing of aged units — ensures consistent chip performance and quality before the module ships. The net effect for a chip designer is freedom: from smartwatches and smart glasses to Bluetooth headsets, SiP integration lets teams customize a solution to the product rather than forcing the product to fit discrete components.
SiP Solutions for Hearables
Hearables are the hardest version of the problem because the available space is so small and the signals are so sensitive. In hearable design, SiP packaging reduces the motherboard area and mitigates RF and audio interference at the same time. That dual benefit matters: shrinking the board frees room to optimize the acoustic cavity for better sound quality and to fit a larger battery for longer playback, while the integration itself reduces the cross-talk that degrades audio.
Acoustic design and active noise control can then be tuned more easily within the reclaimed space. Adding a built-in antenna through an antenna-in-package (AiP) solution goes a step further, optimizing the isolation between the audio path and the RF path so the two no longer interfere. The result is a denser module that simultaneously sounds better and connects more reliably — exactly the combination a true wireless stereo (TWS) earbud needs.
From SiP to Fan-Out SiP: Finer Routing, Fewer Layers
As wearable functions multiply, conventional laminate substrates approach their routing limits. ASE's Fan-Out SiP uses redistribution layers (RDL) as the advanced substrate, delivering finer line width/line spacing than mainstream substrates — about a 5x enhancement in design capability — while cutting roughly three substrate layers out of the stack. Finer routing lets designers match high-frequency signal paths more precisely, and removing layers lowers both profile and cost.
This is the same fan-out lineage that anchors ASE's broader VIPack™ advanced packaging platform, where Fan-Out SiP (FOSiP) sits alongside Fan-Out Chip-on-Substrate (FOCoS) and other pillars. For wearables, it means the miniaturization gains of SiP can continue even after traditional substrates run out of room.
What ASE's SiP Delivers to Customers
Density is only useful if it reaches volume production reliably. ASE's SiP solution is built around four customer outcomes: it reduces inventory and material inspections by consolidating parts, simplifying assembly and testing; it reduces assembly manpower and the number of work processes; it provides customized solutions that meet specific product-design and acoustic specifications; and it reduces time-to-market with a cost-competitive package.
ASE's ATOM earbud reference design makes those claims tangible. Built on the company's SiP platform — and demonstrated with 3D printing for the electro-acoustic components, battery, PCB, microphone, and antenna — the design allows an earbud to be assembled in 2 minutes 42 seconds while achieving extreme miniaturization and active noise cancellation (ANC) performance up to 35dB. The same SiP platform spans a family of standardized footprints, from TWS/hearing modules at 4mm × 8mm and 4.55mm × 9mm to IoT SiP at 6.5mm × 6.5mm and mmWave radar SiP, giving customers proven building blocks rather than a blank sheet.
Where Wearable Packaging Goes Next
Wearables will keep absorbing functions — health sensing, spatial audio, gesture control, always-on connectivity — and every new function competes for the same scarce millimeters. SiP, extended by Fan-Out SiP and the VIPack™ platform, is the mechanism that keeps that competition winnable, packing more capability into less space without sacrificing RF performance or sound quality. As the world's largest outsourced semiconductor assembly and test (OSAT) provider and a leader in SiP from design to high-volume manufacturing, ASE gives wearable makers a turnkey path from reference design to shipped product.
Building your next wearable? Explore how ASE's SiP and Fan-Out SiP solutions miniaturize complete systems from design to volume production at ase.aseglobal.com.
Frequently Asked Questions
Q: What is system-in-package (SiP) and why is it used in wearables? A: SiP integrates multiple chips and functions — MCU, memory, sensors, connectivity, and passives — into a single small module instead of spreading them across a board. ASE can place more than 30 components on a package as small as 4mm × 8mm, which is what lets wearables add functions while shrinking in size and weight.
Q: How does SiP improve hearable and earbud design? A: SiP reduces the motherboard area and mitigates RF and audio interference at once. The reclaimed space can be used to optimize the acoustic cavity for better sound and fit a larger battery, while an antenna-in-package (AiP) solution improves isolation between the audio and RF paths.
Q: What is the difference between SiP and Fan-Out SiP? A: Fan-Out SiP replaces the conventional laminate substrate with redistribution layers (RDL), delivering finer line width/line spacing — about a 5x enhancement — and cutting roughly three substrate layers. This continues miniaturization after traditional substrates reach their routing limits.
Q: How small and fast is ASE's wearable SiP manufacturing? A: ASE's SiP platform spans footprints from 4mm × 8mm TWS/hearing modules to 6.5mm × 6.5mm IoT modules. Its ATOM earbud reference design can be assembled in 2 minutes 42 seconds while reaching active noise cancellation (ANC) up to 35dB.
Q: What are the main benefits of ASE's SiP solution for customers? A: It reduces inventory and material inspections, lowers assembly manpower and work processes, provides customized solutions that meet product-design and acoustic specifications, and shortens time-to-market with a cost-competitive package.
